WAGO 721112026000 12-pole Female Connector
The WAGO 721-112/026-000 is a 12-pole female connector within the MCS – MULTI CONNECTION SYSTEM. It offers universal compatibility for all conductor types and simplifies wiring with vertical and horizontal CAGE CLAMP actuation. The connector includes integrated test ports, provides 100% protection against mismating, and offers coding options for enhanced organization. It is suitable for various industrial applications requiring reliable and efficient connections.
WAGO 721112026000 12-pole Female Connector Specifications:
- Rated voltage (III/3): 320 V
- Rated surge voltage (III/3): 4 kV
- Rated voltage (III/2): 320 V
- Rated surge voltage (III/2): 4 kV
- Nominal voltage (II/2): 630 V
- Rated surge voltage (II/2): 4 kV
- Rated current: 16 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage UL (1977): 600 V
- Rated current UL (1977): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor; with insulated ferrule: 0.25 … 1.5 mm²
- Fine-stranded conductor; with uninsulated ferrule: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- Pole No.: 12
- Total number of connection points: 12
- Total number of potentials: 12
- Pin spacing: 5 mm / 0.197 inch
- Width: 61.5 mm / 2.421 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 26.45 mm / 1.041 inch
- Contact type (pluggable connector): Female connector/socket
- Mismating protection: Yes
- Color: light gray
- Insulation material: Polyamide (PA66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.298 MJ
- Weight: 21.9 g
- Limit temperature range: -60 … +85 °C
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918355483
- Customs tariff number: 85366990990
