WAGO 734103037000 3-pole Female Connector
The WAGO 734-103/037-000 is a 3-pole female connector designed for reliable and efficient electrical connections. Its CAGE CLAMP actuation simplifies wiring, allowing for both vertical and horizontal cable pre-assembly and on-unit wiring. The 100% protection against mismating ensures secure connections, while the locking lever provides added safety. This connector is ideal for use in control cabinets, machinery, and other industrial environments where reliable power distribution is essential. It supports a wide range of conductor types and sizes, offering versatility in various applications.
WAGO 734103037000 3-pole Female Connector Specifications:
- Rated voltage (III/3): 160 V
- Rated surge voltage (III/3): 2.5 kV
- Rated voltage (III/2): 160 V
- Rated surge voltage (III/2): 2.5 kV
- Rated current: 10 A
- Nominal voltage (II/2): 320 V
- Rated surge voltage (II/2): 2.5 kV
- Conductor solid: 0.08 … 1.5 mm² / 28 … 14 AWG
- Conductor fine-stranded: 0.08 … 1.5 mm² / 28 … 14 AWG
- Conductor fine-stranded with insulated ferrule: 0.25 … 1.5 mm²
- Conductor fine-stranded with uninsulated ferrule: 0.25 … 1.5 mm²
- Strip length: 6 … 7 mm / 0.24 … 0.28 inch
- Pole No.: 3
- Pin spacing: 3.5 mm / 0.138 inch
- Width: 22.3 mm / 0.878 inch
- Height: 13.4 mm / 0.528 inch
- Depth: 18.6 mm / 0.732 inch
- Material: Polyamide (PA66)
- Flammability class: V0
- Weight: 2.9 g
- Limit temperature range: -60 … +100 °C
- GTIN: 4044918494458
- Customs tariff number: 85366990990
