WAGO 7933501 1-conductor Double Deck Terminal Block
The WAGO 793-3501 is a versatile terminal block designed for use in industrial control and power distribution systems. Its double deck configuration allows for efficient space utilization on DIN rails. The Push-in CAGE CLAMP® connection technology ensures reliable and tool-free termination of conductors. This terminal block is ideal for applications requiring secure and organized wiring in electrical panels and machinery.
Authorized Distributors
Source:Master Electronics
Part No:793-3501
Stock:26
Inv Date:06-04-2026
Price: Unit price: $7.61
Buy/RFQ:
Source:Onlinecomponents.com
Part No:793-3501
Stock:26
Inv Date:06-04-2026
Price: Unit price: $7.61
Buy/RFQ:
Source:Future Electronics Corporate
Part No:793-3501
Stock:0
Inv Date:06-04-2026
Price: Unit price: $6.67
Buy/RFQ:
WAGO 7933501 1-conductor Double Deck Terminal Block Specifications:
- Rated voltage (III / 3): 690 V
- Rated impulse voltage (III / 3): 6 kV
- Rated current: 24 A
- Rated current (2): 28 A
- Connection technology: Push-in CAGE CLAMP®
- Actuation type: Open Tool Slot
- Connectable conductor materials: Copper
- Nominal cross section: 2.5 mm²
- Solid conductor: 0.25 … 4 mm² / 22 … 12 AWG
- Solid conductor, push-in termination: 0.75 … 4 mm² / 18 … 12 AWG
- Fine-stranded conductor: 0.25 … 4 mm² / 22 … 12 AWG
- Strip length: 10 … 12 mm / 0.39 … 0.47 inch
- Total number of connection points: 2
- Total number of potentials: 2
- Number of levels: 2
- Type of wiring: Front-entry wiring
- Width: 5.2 mm / 0.205 inch
- Height from upper-edge of DIN-35 rail: 51.3 mm / 2.02 inch
- Depth: 80.1 mm / 3.154 inch
- Design: horizontal
- Type of mounting: DIN-35 rail
- Potential marking: L/L
- Marking level: Side marking
- Insulating material: Polyamide 66 (PA 66)
- Fire load: 0.245 MJ
- Weight: 11.749 g
- Product Group: 18 (X-COM-System)
- Country of origin: DE
- GTIN: 4045454916503
- Customs Tariff No.: 85369010000
Buy the 793-3501 WAGO 1-conductor Double Deck Terminal Block | myMectronic
Purchase the WAGO 793-3501 terminal block securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 7933501?
You can click on the BUY or RFQ button to purchase 7933501 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 7933501?
You can download the 7933501 datasheet or visit the WAGO website for support.
Who is the manufacturer of 7933501?
WAGO
