WEIDMULLER 1014460000 Signal PCB Connector
The OMNIMATE Signal series BL/SL 5.08 BLF 5.08HC/10/180LR SN OR BX is a PCB plug-in connector designed for reliable and tool-free wire connection. Featuring a 5.08 mm pitch, 10 poles, and a push-in connection system, it offers high current capability with rated currents up to 24 A and voltages up to 400 V. Its compact, female connector design includes flexible outlet directions and multiple flange options, making it suitable for diverse automation and control applications. Constructed with tinned copper contacts, it meets IEC, UL, and CSA standards for safety and durability.
WEIDMULLER 1014460000 Signal PCB Connector Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 10
- Rated voltage: 400 V (IEC), 300 V (UL), 300 V (CSA)
- Rated current: 24 A (IEC), 18.5 A (UL), 10 A (CSA)
- Clamping range: 0.13 mm² to 3.31 mm² (AWG 26 to AWG 12)
- Insulating material: PBT, orange color, UL 94 V0 rated
- Contact material: Copper alloy, tinned surface
- Contact thickness: 4-8 μm Sn, hot-dip tinned
- Temperature range: -30°C to 100°C
- Protection class: IP20
- Push-in connection, tool-free wiring
- Steady designed for >25 plug cycles
- Recommended stripping length: 10 mm
- Compatible with wire end ferrules with or without plastic collar
- Dimensions: length approx. 45.72 mm, width 14 mm
- Standards: IEC 60999, DIN VDE 0711, UL, CSA
Buy the Weidmueller Series BL/SL 5.08 PCB Connector: 1014460000
Enhance your wiring installations with the Weidmueller Signal PCB Connector, featuring a compact design, push-in connection, and high current ratings. Its easy tool-free wiring simplifies installation in automation, control, and industrial systems. Constructed with durable, tinned copper contacts and rated for voltages up to 400 V, this connector provides reliable connections for various wire sizes from AWG 26 to AWG 12. Its IP20 protection class ensures safety in typical control cabinet environments, making it a perfect choice for professional and efficient electrical connections.
Buy Weidmueller series BL/SL 5.08 connector with push-in system now and experience reliable, tool-free wiring in automation and control projects.
