WEIDMULLER 1059630000 Power Header
The high-performance female header is designed for UL-6OOV applications in the lower performance range up to 12 kVA. It features a compact and efficient design with a 7.62 mm pitch, 10 poles, and a clamping yoke connection for secure wire termination. Suitable for wires from 0.2 mm² to 4 mm² (AWG 28-12), the connector meets safety standards including touch safety per IEC 68 100-5-1 and UL 600 V/20 A ratings. It offers reliable electrical connection, easy installation with a stripping length of 7 mm, and is ideal for industrial power distribution and device integration.
WEIDMULLER 1059630000 Power Header Specifications:
- Rated voltage: IEC 630 V, UL 600 V, CSA 600 V
- Rated current: IEC 29A, UL 20A, CSA 20A
- Poles: 10, Pitch: 7.62 mm (0.3 inch), Conductor outlet direction: 180°
- Wire connection: Clamping yoke, min. 0.2 mm?, max. 4 mm?, compatible with AWG 28-12
- Insulating material: PBT, Color: Black, Flammability rating: UL 94 V-0
- Contact material: Copper alloy, Tinned surface, Layer thickness: 4-8 um Sn
- Operating temperature: -60°C to 100°C, Storage temperature: -25°C to 55°C, Max. humidity: 80%
- Tightening torque: 0.4-0.5 Nm, Min. stripping length: 7 mm
- Dimensions: Length 68.58 mm (2.7 inches), Width approx. 14 mm, No. of rows: 1
- Approvals: UL, IEC, CSA, Conforms to IPC standards, Compatible with DIN 46228 wire ferrules
Buy the Weidmueller 1059630000 – Reliable Power Header for Industrial Applications
Upgrade your industrial power distribution system with the high-performance power header. Designed for UL and IEC compliance, it features secure clamping for wires from 0.2 mm² to 4 mm², ensuring safe and reliable connections up to 600V and 20A. Its compact design with a 7.62 mm pitch, single-row configuration, and easy installation makes it perfect for device manufacturers and automation engineers. Trust Weidmueller's quality standards to deliver durability and safety to your power on board applications. Buy online today for fast, dependable delivery and enhance your project’s performance.
Order your Weidmueller Series BLZ 7.62HP power header today and ensure secure, reliable power distribution in your industrial projects.
