WEIDMULLER 1123970000 Relay Base
The TRS 12VDC 2CO EMPTY relay base by Weidmueller Series offers a reliable and versatile connection platform designed for industrial automation. It features a compact 12.8 mm width, a height of 89.6 mm, and a depth of 87.8 mm, supporting screw connection with a tightening torque of 0.4 Nm. Designed for use with 12 V DC control voltage, it accommodates a maximum continuous current of 10 A and operates safely in temperatures from -40°C to 85°C. Its sturdy, UL 94 V-0 rated body ensures durability and compliance with environmental standards, making it suitable for various control applications.
WEIDMULLER 1123970000 Relay Base Specifications:
- Width: 12.8 mm (0.504 inch)
- Height: 89.6 mm (3.528 inch)
- Depth: 87.8 mm (3.457 inch)
- Net weight: 429 grams
- Operating temperature: -40°C to 85°C
- Storage temperature: -40°C to 85°C
- Rated control voltage: 12 V DC ±20%
- Continuous current: 10 A
- Connection cross-section: min. AWG 26, max. AWG 14
- Tightening torque: 0.4 Nm
- Pollution severity level: 2
- Dielectric strength input/output: 1.2 kV for 5 seconds
- Protection degree: IP20
- Flammability rating: UL 94 V-0
- Surge voltage category: WW
- Impulse withstand voltage: 6 kV (1.2/50 μs)
Buy the Weidmueller Series TRS 12VDC 2CO: 1123970000
Purchase the Weidmueller Series TRS 12VDC 2CO relay base online today to ensure reliable automation control. Featuring a compact 12.8 mm width, durable UL 94 V-0 rated body, and supporting up to 10 A, this relay base is ideal for industrial environments. Its screw connection method with a tightening torque of 0.4 Nm ensures secure wiring, while operating temperature range of -40°C to 85°C guarantees performance in diverse conditions. Reliable, safe, and compatible with various control systems—order now for seamless automation integration.
Get Weidmueller TRS 12VDC 2CO today—built for precision and long-lasting durability in industrial control applications.
