WEIDMULLER 1127050000 Solid-State Relay Module
The WEIDMULLER TERMSERIES TOZ 24VDC 48VDC0,1A is a compact solid-state relay module suitable for various industrial automation and control applications. It combines a solid-state relay with a base, offering AC/DC/UC input options and multiple voltage inputs (24-230V UC). Protective circuits like free-wheel diodes and RC elements enhance reliability. The module's tension clamp connection simplifies wiring, and it's available in a 6.4mm width, making it ideal for space-constrained environments. It is designed for mounting on TS 35 rails and offers robust insulation coordination and protection.
WEIDMULLER 1127050000 Solid-State Relay Module Specifications:
- Base Series: TERMSERIES
- Rated Control Voltage: 24 V DC ±20 %
- Rated Switching Voltage: 0…48 V DC
- Continuous Current: 100 mA
- Switch-off Delay: < 600µs
- Leakage Current: < 10µA
- Mounting Rail: TS 35
- Width: 6.4 mm
- Height: 90.5 mm
- Depth: 87.8 mm
- Net Weight: 29.3 g
- Operating Temperature Min: -20 °C
- Operating Temperature Max: 60 °C
- Storage Temperature Min: -40 °C
- Storage Temperature Max: 70 °C
- MTTF: 3,765 Years
- Power Rating: 280 mW
- Cut-in Current: 4.8 mA DC
- Cut-out Current: 3.2 mA DC
- Contact Type: 1 NO contact (Bipolar transistor)
- UL 94 Flammability Rating: V-0
- Pollution Severity: 2
- Clearance and Creepage Distances: ≥ 5.5 mm
- Dielectric Strength Control-Load Side: 2.5 kVeff
- Impulse Withstand Voltage: 6 kV (1.2/50 µs)
- Connection Method: Tension clamp connection
- Clamping Range: 1.5 mm²
- Max AWG: AWG 14
- Stripping Length: 8 mm
