WEIDMULLER 1149440000 Pin Header
The SL 5.08HC/04/90LF pin header from Weidmüller's OMNIMATE Signal series is a 4-pole, PCB plug-in connector with a 5.08 mm pitch. Made from glass-fibre-reinforced plastic, it features a solder flange for THT connection, with a solder pin length of 3.2 mm. Its compact design includes an orange insulating body, UL and IEC ratings up to 400 V/24A, and UL 94 V-0 flammability. Designed for robust electronic assemblies, it offers reliable electrical contact and mechanical stability for industrial and control applications.
WEIDMULLER 1149440000 Pin Header Specifications:
- Number of poles: 4
- Pitch: 5.08 mm (0.2 inch)
- Solder pin length: 3.2 mm ±0.17 mm
- Solder eyelet diameter: 1.3 mm
- Insulating material: PA GF Orange (RAL 2000)
- Contact material: CuMg, nickel/solder plating
- Rated voltage: 400 V IEC, 300 V UL
- Rated current: 24 A IEC, 18.5 A UL
- Operating temperature: -50°C to +100°C
- Flammability: UL 94 V-0
- Number of solder pins per pole: 1
- Solder pin dimensions: d=1.2 mm, octagonal
- Packaging: Box
- Connection type: PCB plug-in with solder flange
- Number of plugging cycles: 25
Buy the Weidmueller Series OMNIMATE Signal: SL 5.08HC/04/90LF 3.2SN OR BX
Purchase the Weidmueller OMNIMATE Signal pin header SL 5.08HC/04/90LF online today. This 4-pole connector with a 5.08 mm pitch offers high quality and dependable electrical connections. Made from durable glass-fibre-reinforced plastic with UL and IEC approvals, it features a solder flange for easy THT assembly, with a solder pin length of 3.2 mm. Its compact orange design provides excellent mechanical stability and reliability ideal for industrial control and electronic applications. Secure your PCB assembly now with this reliable connector.
Order your Weidmueller Series OMNIMATE Signal pin header SL 5.08HC/04/90LF today and ensure reliable PCB connections for industrial control and automation projects.
