WEIDMULLER 1226500000 PCB Terminal
The Weidmueller LX series PCB terminal is designed for reliable and secure wire connections in industrial control and automation systems. Featuring a 15.00 mm pitch with six poles, it supports conductor sizes from 1.50 to 25 mm² and wire types including solid, stranded, and flexible conductors with or without ferrules. Its clamping yoke connection ensures high mechanical stability, with a maximum rated voltage of 1000 V (IEC) and 600 V (UL). Constructed from durable materials with a black tin-plated copper contact surface, it offers excellent insulation, operational temperature range from -60°C to 120°C, and compliance with international standards.
WEIDMULLER 1226500000 PCB Terminal Specifications:
- Pitch: 15 mm (0.591 inch)
- Number of poles: 6, No. of solder pins per pole: 2
- Solder pin length: 4.5 mm, Dimensions: 12 x 1.2 mm
- Rated voltage: 1000 V IEC / 600 V UL
- Rated current: 101 A IEC / 85 A UL
- Clamping range: 1.31 mm to 25 mm
- Wire cross section: AWG 16 to AWG 4, compatible with solid, stranded, flexible wires, and wire end ferrules
- Insulating material: Wemid (PA), black, Flammability rating V0, CTI > 600
- Contact material: Copper, with Nickel and Tin plating
- Operating temperature: -60°C to 120°C, Storage: -25°C to 55°C, Max humidity: 80%
- Certifications: UL, IEC, RoHS conforming
Buy the Weidmueller LX 1226500000 – Reliable PCB Terminal for Industrial Applications
Order the Weidmueller LX PCB terminal online today for secure, reliable wire connections in automation and industrial control projects. Its robust clamping yoke connection supports conductor sizes from 1.50 to 25 mm², offering high rated voltage and current for safe operation. Made from durable materials with excellent insulation, the terminal ensures long-term performance across a wide temperature range. Perfect for precise wiring, it simplifies installation and maintenance, making it a vital component for engineers and technicians aiming for quality and reliability in control panels.
Get Weidmueller LX 1226500000 today—built for precise wiring and long-lasting durability in industrial control systems.
Frequently Asked Questions
Where can I buy WEIDMULLER 1226500000?
You can click on the BUY or RFQ button to purchase 1226500000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1226500000?
You can download the 1226500000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1226500000?
WEIDMULLER
