WEIDMULLER 1234620000 PCB Terminal
The PCB terminal with leaf spring connection is designed for 5.08 mm pitch with 10 poles, providing reliable pressure clamp connection and suitability for conductor cross-sections up to 2.5 mm². It features a 90° conductor outlet, solder pin length of 3.5 mm, and is rated for 600 V and 24 A according to IEC standards. Made from orange Wemid (PA) and copper alloy, it ensures excellent insulation resistance and flame retardancy. Ideal for industrial automation and PCB applications, it meets touch-safe and UL/VDE safety standards, perfect for reliable electrical connections in diverse environments.
WEIDMULLER 1234620000 PCB Terminal Specifications:
- Pitch: 5.08 mm (0.2 inch)
- Number of poles: 10
- Conductor cross-section: 0.13 - 2.5 mm² (AWG 26-14)
- Rated voltage: IEC 600 V, UL 300 V
- Rated current: IEC 24 A, UL 15 A
- Pin length: 3.5 mm
- Material: Insulating Wemid (PA), contact copper alloy, tinned surface
- Insulation resistance: >10^9 Ω
- Flammability rating: UL 94V-0
- Solder eyelet hole diameter: 13 mm
- Solder pin diameter: 1.0 mm
- Tightening torque: 0.4–0.5 Nm
- Temperature range: -60°C to +120°C
- Clamping range: 0.13 - 2.5 mm²
- Conductor outlet angle: 90°
- Protection rating: IP20
- Compliance: IEC, UL, CSA standards
- Storage temperature: -25°C to +55°C
- Maximum humidity: 80% during storage
Buy the Buy Weidmueller PCB Terminal Part Number 1234620000 Online
Purchase the Weidmueller PCB terminal with 10 poles, 5.08 mm pitch, and pressure clamp connection online today. Designed for conductor cross-sections up to 2.5 mm², rated for 600 V and 24 A, it features a 90° outlet, bright orange Wemid insulator, tinned copper contacts, and proven safety standards. Perfect for industrial automation, control panels, and PCB assemblies, this reliable terminal offers excellent insulation, safety, and durability. Ensure seamless installation and maintenance, order now to enhance your electrical projects with superior quality parts.
Order your Weidmueller SeriesPM PCB terminal with 10 poles and 5.08 mm pitch today and ensure dependable, high-quality electrical connections for your projects.
Frequently Asked Questions
Where can I buy WEIDMULLER 1234620000?
You can click on the BUY or RFQ button to purchase 1234620000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1234620000?
You can download the 1234620000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1234620000?
WEIDMULLER
