WEIDMULLER 1498100000 HDC Insert Male Connector
The Weidmuller HDC HA 3 MS insert is a robust and compact connector solution designed for applications where space is at a premium. This insert, part of the HDC series, offers a reliable screw connection for secure electrical connections. With a 3-pole configuration, it's suitable for a range of signal and power transmission needs. Rated for 16A and 400V, it provides dependable performance in industrial automation, control panels, and machinery. The insert's compact dimensions and robust construction ensure longevity and ease of integration into various systems.
WEIDMULLER 1498100000 HDC Insert Male Connector Specifications:
- Rated current: 16 A
- Rated voltage: 400 V
- Rated voltage acc. to UL/CSA: 600 V AC/DC
- Pole count: 3
- Conductor cross-section: 2.5 mm²
- Material: Copper alloy
- Insulating material: PC glass-fibre reinforced
- Pollution severity: 3
- Rated impulse voltage: 4 kV
- Size: 1
- Volume resistance: ≤ 2mΩ
- Tightening torque for main contact: 0.5 Nm
- Plugging cycles: ≥ 500
- Surface finish: Silverpassivated
- UL 94 flammability rating: V-0
- Length: 21 mm
- Width: 21 mm
- Height: 36.5 mm
- Net weight: 15 g
- Limit temperature: -40 °C ... 125 °C
