WEIDMULLER 1972300000 Industrial PCB Connector
The Weidmüller BCF 3.81/12/180LR SN offers a compact, push-in connection system for reliable electrical wiring in industrial applications. This PCB plug connector features 12 poles with a 3.81 mm pitch, designed for fast, tool-free wiring and high-density layouts with a 180° outlet direction. Made from flame-retardant PA GF in vibrant orange, it provides 320V/17.5A rated current, suitable for wire cross-sections from 0.14 mm² to 1.5 mm². The connector supports multiple standards, ensuring safe, efficient, and vibration-resistant connections for automation and control systems.
WEIDMULLER 1972300000 Industrial PCB Connector Specifications:
- Pitch: 3.81 mm (0.15 inch)
- Number of poles: 12
- Outlet direction: 180°
- Rated voltage: 320V
- Rated current: 17.5A
- Wire cross-section range: 0.14 mm² to 1.5 mm²
- Clamping range: 0.14 mm² to 1.5 mm²
- Material: PA GF, flame rated V-0 (UL94)
- Color: Orange (RAL 2000)
- Insulation resistance: 210 MΩ
- Touch-safe protection: IP20
- Flammability rating: UL 94 V-0
- Screwdriver compatible: 0.4 x 2.5 mm
- Max. actuating force: 40 N
- Plugging cycles: 25
- Operating temperature: -60°C to 120°C
- Storage temperature: -25°C to 55°C
Buy the Weidmueller Series BC/SC 3.81 Connectors: 1972300000
Secure your automation projects with the Weidmueller Series BC/SC 3.81 PCB connector. Featuring 12 poles, a 3.81 mm pitch, and push-in connection technology, this high-quality component guarantees quick assembly, dependable performance, and vibration resistance. Made with flame-retardant materials, it supports a wide range of wire sizes from 0.14 mm² to 1.5 mm², and seamlessly integrates into control panels and automation systems. Order online now for fast delivery and professional-grade connectivity.
Order your Weidmueller Series BC/SC 3.81 connector today and ensure reliable, quick, and safe wiring for your industrial automation projects.
Frequently Asked Questions
Where can I buy WEIDMULLER 1972300000?
You can click on the BUY or RFQ button to purchase 1972300000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1972300000?
You can download the 1972300000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1972300000?
WEIDMULLER
