WEIDMULLER 1985590000 Spring Connection Terminal Block
The WEIDMULLER ZQV 1.5N/5 BL is a spring connection terminal block designed with innovative PUSH IN technology. This technology significantly reduces wiring time while ensuring high conductor pull-out forces and ease of handling for all conductor types. Constructed from durable Wemid material with a V-0 flammability rating, this terminal block is suitable for a wide range of industrial applications. It is explosion-tested and features a plugged fixing type. Note that breaking out more than 60% of contact elements may impact stability and temperature, and cross connectors reduce the rated voltage.
WEIDMULLER 1985590000 Spring Connection Terminal Block Specifications:
- Width: 16 mm
- Height: 21.9 mm
- Depth: 2.8 mm
- Net weight: 1.537 g
- Width(inches): 0.63 inch
- Height(inches): 0.862 inch
- Depth(inches): 0.11 inch
- Storage temperature max: 55 °C
- Storage temperature min: -25 °C
- Material: Wemid
- UL 94 flammability rating: V-0
- Colour: blue
- Explosion-tested version: Yes
- Type of fixing: Plugged
- Pitch in mm (P): 3.5 mm
- Rated current: 17.5 A
- ETIM 6.0: EC000489
- eClass 9.0: 27-14-11-40
- eClass 10.0: 27-14-11-40
- ETIM 7.0: EC000489
- eClass 9.1: 27-14-11-40
Buy the 1985590000 WEIDMULLER Spring Connection Terminal Block | myMectronic
Purchase the WEIDMULLER 1985590000 ZQV 1.5N/5 BL terminal block securely and efficiently online.
