WEIDMULLER 2439680000 PCB Connector
The Weidmiiller OMNIMATE Signal series BL/SL 2.50 is a versatile PCB plugin connector with push-in technology, designed for quick, reliable wire connections in automation and electrical systems. It features a pitch of 2.50 mm, five poles, and a robust copper alloy contact surface with a tin finish. Suitable for operating temperatures from -40°C to 105°C, it supports wire sizes from AWG 28 to AWG 20 and is rated for 6A at 320V. Its compact, space-saving design ensures high-density component placement while maintaining safety and ease of handling.
WEIDMULLER 2439680000 PCB Connector Specifications:
- Pitch in mm: 2.50 mm
- Number of poles: 5
- Operating temperature: -40°C to 105°C
- Rated voltage: 320V
- Rated current: 6A
- Wire size range: AWG 28 to AWG 20
- Connection method: Push-in direct insertion
- Contact material: Copper alloy, tinned
- Insulating material: PA (Polyamide)
- Flammability rating: UL 94 V-0
- Color: Black (RAL 9011)
- Protection class: IP 20
- Stripping length: 8mm
- Number of rows: 1
- Plugging cycles: 25
- Dimensions: Length approx. 10mm, suitable for high-density installation
- Certifications: UL, CSA, IEC compliance
Buy the Weidmiiller Series BL/SL 2.50 PCB Connector: 2439680000
Discover the convenience and reliability of the Weidmiiller Series BL/SL 2.50 PCB connector. Engineered for quick, secure wire connections, it features push-in technology, a compact design, and a rated capacity of 6A at 320V. Suitable for automation projects, control panels, and electrical installations, this high-quality connector ensures safety, durability, and ease of handling. Upgrade your wiring systems today with this robust and space-efficient component, available for online purchase at competitive prices to meet demanding industrial standards.
Order your Weidmiiller Series BL/SL 2.50 PCB connector today and upgrade your electrical systems with reliable, easy-to-install wire connections.
Frequently Asked Questions
Where can I buy WEIDMULLER 2439680000?
You can click on the BUY or RFQ button to purchase 2439680000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2439680000?
You can download the 2439680000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2439680000?
WEIDMULLER
