WEIDMULLER 2473010000 Power Connector
The LLFS 7.50/03/90V 5.0SN BK BX is a robust, high-current PCB terminal designed for power electronics applications including solar inverters, servo-controllers, and power supplies. It features a push-in connection method without an actuator, 7.50mm pitch, and three poles with 5mm solder pin length. Made from flame-retardant Wemid (PA) in black, it offers safe finger-touch protection (IP20) and is rated for up to IEC 1000V/41A. Suitable for solid and flexible conductors from 0.25 mm² to 6 mm² for reliable, secure wiring in demanding environments.
WEIDMULLER 2473010000 Power Connector Specifications:
- Width: 23.5mm (0.925 inch)
- Height: 30.56mm (1.203 inch), lowest version 25.56mm
- Depth: 20.05mm (0.789 inch)
- Material: Wemid (PA), black, UL 94 V0 flammability rating
- Contact Material: E-Cu, tinned surface
- Number of Poles: 3
- Pitch: 7.5mm (0.295 inch)
- Solder pin length: 5mm
- Solder eyelet hole diameter: 2mm (+0.1mm tolerance)
- Conductor range: 0.25 mm² to 6 mm² (solid and flexible)
- Operating temperature: -40°C to +120°C
- Rated voltage IEC: 1000V
- Rated current IEC: 41A (minimum), 37A (maximum, at 40°C)
- Rated current UL/CSA: 37A, 600V
- Clamping range: 0.25 mm² to 6 mm²
- Protection IP20, finger-safe according to DIN VDE 0470
- Flammability rating: UL 94 V0
Buy the Weidmueller Series LL Power Connector: LLFS 7.50/03/90V 5.0SN BK BX
Purchase the Weidmueller Series LL power connector LLFS 7.50/03/90V 5.0SN BK BX online now for secure, high-current electrical connections. Its robust design, 7.50mm pitch, three poles, and rated IEC voltage of 1000V make it ideal for power electronics, solar, and industrial applications. Featuring push-in wire connection without actuator and finger-safe IP20 protection, it ensures quick, safe assembly and reliable operation in demanding environments. Ordering online provides fast delivery and trusted quality for your technical projects.
Order your Weidmueller Series LL power connector LLFS 7.50/03/90V 5.0SN BK BX today and enjoy reliable, high-current wiring solutions perfect for demanding power electronics projects.
