WEIDMULLER 2473030000 Power PCB Terminal
The OMNIMATE Power series LLFS 7.50/05/90V 5.0SN BK BX is a robust, high-current PCB terminal designed for power electronics applications like solar inverters, frequency converters, and power supplies. It features a 7.50 mm pitch, 5 poles, tinned copper contacts, and a push-in connection method for reliable, tool-free wiring. The terminal withstands 1000 V IEC standards, operates up to 120°C, and ensures finger-safe IP20 protection, making it ideal for demanding electrical environments requiring secure and high-capacity connections.
WEIDMULLER 2473030000 Power PCB Terminal Specifications:
- Width: 38.5 mm (1.516 inch)
- Height: 30.56 mm (1.203 inch)
- Depth: 20.05 mm (0.789 inch)
- Operating temperature: -40°C to 120°C
- Rated voltage: IEC 1000 V, UL 600 V
- Rated current: IEC 41A, UL 37A
- Number of poles: 5
- Pitch: 7.5 mm (0.295 inch)
- Solder pin length: 5 mm
- Material: Insulating Wemid (PA), contact made of E-Cu, tinned surface
- Clamping range: 0.25 mm² to 6 mm² (solid & flexible conductors)
- Insulation strength: 210°C UL 94 V0 flammability
- Protection class: IP20 (touch-safe)
- Dimensions: Width 38.5 mm, height 30.56 mm, depth 20.05 mm
- Weight: approximately 20.24 grams
Buy the Buy Weidmueller Power Series LLFS 7.50/05/90V 5.0SN BK BX Part Number 2473030000 Online
Discover the Weidmueller Power Series LLFS 7.50/05/90V 5.0SN BK BX, a essential high-current PCB terminal suitable for demanding power electronic systems. Featuring a 7.50 mm pitch, five poles, and a push-in connection, it guarantees secure wiring and excellent electrical performance up to 120°C. Rated for 1000 V IEC and 600 V UL, its robust construction supports currents up to 41 A IEC and 37 A UL. Easy to install, cost-effective, and compliant with international standards, it’s ideal for industrial and energy applications. Shop online now for fast delivery and reliable power connections.
Order your Weidmueller Series LLFS 7.50/05/90V 5.0SN BK BX today and ensure reliable high-current connections for power electronics applications.
Frequently Asked Questions
Where can I buy WEIDMULLER 2473030000?
You can click on the BUY or RFQ button to purchase 2473030000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2473030000?
You can download the 2473030000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2473030000?
WEIDMULLER
