WEIDMULLER 2476680000 Control Relay
The Weidmueller D-SERIES DRI DRIKIT 24VDC 1CO LD is a fully assembled relay kit designed for reliable switching and control applications. It includes a relay, base, and retaining clip, tested for perfect functionality, with a bright status LED for easy monitoring. The relay features a single contact with AgSnO contact material, rated at 10 A, and operates on 24 V DC control voltage. Its compact size and screw connection make it suitable for automation and control panel integration, with high dielectric strength and UL/cURus certification ensuring safety and durability.
WEIDMULLER 2476680000 Control Relay Specifications:
- Dimensions: Width 15.8 mm, Height 80.2 mm, Depth 67.7 mm
- Weight: 58.89 g
- Operating temperature: -40°C to 55°C
- Control Voltage: 24 V DC, ±10%
- Control Current: 21.8 mA
- Rated Control Power: 530 mW
- Switching Voltage: Max. 250 VAC/DC
- Max. Switching Current: 10 A
- Contact Type: 1CO (AgSnO)
- Mechanical Life: 10^10 switching cycles
- Dielectric Strength: 4 kV between input/output
- Certifications: UL, cURus, RoHS
- Connection Method: Screw terminal, 8 mm stripping length
- Pull-In Voltage: Typ. 18 V, Drop-Out Voltage: 3.6 V
- Switching Capacity: Resistive load up to 2500 VA (AC), 240 W (DC)
- Protection Degree: IP20
- Standards: IEC 61810-1, EN 60664-1, EN 61000-6-2/4
Buy the Buy Weidmueller D-SERIES DRI DRIKIT 24VDC 1CO LD Part Number 2476680000 Online
Purchase the Weidmueller D-SERIES DRI DRIKIT 24VDC 1CO LD relay kit online today. This fully assembled, function-tested control relay features a high-quality AgSnO contact, rated at 10 A, and operates reliably on 24 V DC. Its compact design includes a bright green LED indicator for status, screw terminal connections for easy installation, and high dielectric strength for safety. Ideal for automation, control panels, and industrial applications, this relay ensures dependable performance and long service life in demanding environments.
Get Weidmueller DRIKIT 24VDC 1CO LD today—built for precise control and long-lasting durability.
