WEIDMULLER 2617890000 Industrial Relay Module
The TERMSERIES relay module with a 1CO AgSnO contact offers reliable switching with a rated control voltage of 48 V UC and a continuous current of 6 A. Its compact dimensions (Width 6.4mm, Height 89.4mm, Depth 87.8mm) make it suitable for various control panel applications. The module features a green LED status indicator, UL 94 V0 flammability rating, and robust dielectric strength of 4 kV. Designed with push-in connection and AC/DC/UC coils, it supports multiple protective circuits like free-wheel diodes and RC elements, ensuring durability and operational efficiency in industrial environments.
WEIDMULLER 2617890000 Industrial Relay Module Specifications:
- Width: 6.4 mm (0.252 inch)
- Height: 89.4 mm (3.52 inch)
- Depth: 87.8 mm (3.457 inch)
- Net weight: 309 g
- Operating temperature: -40°C to 60°C
- Storage temperature: -40°C to 85°C
- Relative humidity: 5-95%
- Rated control voltage: 48 V UC + 10%
- Rated current AC: 8 mA
- Rated current DC: 7 mA
- Maximum switching voltage: 250 VAC/DC
- Mechanical life: 5 x 10^6 switching cycles
- Contact material: AgSnO
- Continuous current: 6 A
- Max switching capacity: 1500 VA (AC), 144 W (DC)
- Connection: Push-in, 8 mm stripping
- Flammability rating: UL 94 V0
- Dielectric strength: 4 kV (input/output)
- Surge voltage category: UL
- Protection degree: IP20
- Max. altitude: 2000 m
Buy the Weidmueller Series TRP 48VUC 1CO: 2617890000
Order the Weidmueller relay module online today and ensure reliable switching in your automation projects. Featuring 48 V control voltage, 6 A capacity, and robust AgSnO contacts, it’s ideal for industrial control panels. Its compact size, push-in connection, and status indicator make installation straightforward while providing durability through UL 94 V0 flammability and IP20 protection. Enhance your automation system's efficiency and safety by purchasing this high-quality relay module directly from trusted online sources today.
Buy Weidmueller TRP 48VUC 1CO relay module now and experience unmatched reliability and performance in industrial control systems.
Frequently Asked Questions
Where can I buy WEIDMULLER 2617890000?
You can click on the BUY or RFQ button to purchase 2617890000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 2617890000?
You can download the 2617890000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 2617890000?
WEIDMULLER
