Weidmuller BL5088 Terminal Block
The Weidmuller BL 5.08/8 is an 8-pole, 5.08 mm pitch PCB female terminal block featuring a pressure clamp connection. It is designed for wire sizes from 26 AWG to 14 AWG and is made from durable polyamide (PA) insulation. The terminal block is orange in color, with copper-tin contact material finished with tin for reliable electrical contact. It provides a conductor outlet orientation of 180°, ensuring easy wiring access. The device has a net weight of approximately 10.73 grams. It is UL 1059 listed, CSA certified, and offers IP00 touch-safe protection suitable for industrial applications.
Weidmuller BL5088 Terminal Block Specifications:
- Pitch in mm: 5.08 mm
- Number of poles: 8
- Wire connection method: Pressure clamp connection
- Rated voltage: 400 V / 148 V / 0.2-1.5 mm²
- Rated current: 10A (IEC, UL, CSA)
- Conductor range: AWG 26 to AWG 14
- Material: Polyamide (PA), Insulating material, orange color
- Contact material: CuSn, Tinned
- Contact surface: Tinned layer 4-8 μm
- Ingress protection: IP00
- Operating temperature: -60°C to +100°C
- Clamping range: Min 0.13 mm², Max 2.08 mm²
- Stripping length: 6 mm
- Tightening torque: Min 0.4 Nm, Max 0.5 Nm
- Torsion: 25 plugging cycles
- Mounting: PCB, with 180° conductor outlet
- Dimensions: 35.56 mm length, 14 mm width
Buy the Buy Weidmuller BL 5.08/8 Part Number BL5088 Online
Purchase the Weidmuller BL 5.08/8 terminal block online today to ensure a high-quality, reliable connection for your industrial wiring needs. This 8-pole, 5.08 mm pitch PCB female terminal features a pressure clamp system for fast, secure wiring and is suitable for wire sizes from 26 to 14 AWG. Made from durable polyamide with copper-tin contact surfaces, it guarantees long-lasting electrical performance. Certified according to UL and CSA standards, it offers IP00 touch safety, ideal for control panels and automation devices. Order now to streamline your installation process.
Order your Weidmuller SeriesBL 5.08/8 BL5088 today and equip your projects with a reliable, highly durable PCB terminal block featuring a user-friendly pressure clamp connection.
