Weidmuller SL5081690B PCB Female Header
This PCB male header connector features a 5.08 mm pitch with 16 poles, designed for PCB mounting with THT soldering. Its 90° outlet configuration and solder pin length of 3.2 mm optimize wave soldering processes. The connector is coated in orange PBT, ensuring high insulation and durability. Suitable for industrial, automation, and electrical applications, it supports rated voltages up to 400 V IEC and 300 V UL/CSA, with a rated current of 18A. Its compact design, with a weight of approximately 5.139 grams, makes it ideal for space-conscious electronic assemblies.
Weidmuller SL5081690B PCB Female Header Specifications:
- Pitch in mm: 5.08 mm
- Number of poles: 16
- Solder pin length: 3.2 mm
- Solder pin dimensions: d=1.2 mm, octagonal
- Solder eyelet hole diameter: 1.3 mm
- Operating temperature range: -60°C to 100°C
- Maximum rated voltage: 400 V IEC, 300 V UL/CSA
- Rated current: 18A ( IEC ), 15A ( UL/CSA )
- Material: PBT insulating body, CuSn contact surface, tinned
- Color: Orange (similar to RAL 2000)
- Number of rows: 1
- Mounting: PCB through-hole (THT)
- Flammability rating: UL 94 V-0
- Layer structure of solder contact: Ni / Sn layers, 1-3 μm Ni, 2-4 μm Sn
- Protection class: IP20 when plugged
- Certification: UL, CSA compliant
- UL/CSA Certificate No.: E60693, 200039-1121690
Buy the Buy Weidmuller Signal Series Connector Part Number SL5081690B Online
Purchase the Weidmuller PCB male header connector online today to ensure your electronic assembly benefits from high-quality, durable, and reliable connectivity solutions. Designed for precise wave soldering, with a compact design and rated for up to 400 volts and 18 amps, this connector guarantees safety and performance in industrial and automation applications. Whether implementing new systems or maintaining existing installations, online procurement guarantees quick delivery, superior quality, and secure handling, making it an essential component for your electrical projects.
Get Weidmuller SL5081690B today—engineered for reliable electrical connections with high current capacity and robust PCB mounting features.
