WIELAND ELECTRIC 0725016270 Terminal Strip Connector
Wieland Electric's KL 16 PA terminal strips offer a durable and reliable connection solution for demanding industrial environments. Constructed with a polyamide 6 housing, nickel-plated brass clamping body, and phosphor bronze wire protection, these terminal strips are designed to withstand extreme conditions as defined by EN 60335-1/DIN VDE 0700 T1. The clamping screws are secured against loosening, ensuring vibration-proof connections. Available with or without wire protection (DS), these terminal strips are ideal for applications requiring secure and long-lasting electrical connections.
WIELAND ELECTRIC 0725016270 Terminal Strip Connector Specifications:
- Material: Polyamide 6 ivory
- Hardness test: 125 °C
- Glow-wire test: 850 °C
- Tracking test: PTI 250
- Clamping body: nickel-plated brass
- Wire protection: phosphor bronze
- Clamping screws: steel, zinc-plated and dichromated
- DIN VDE: 0110 (fixed position)
- UL ratings: Available
- CSA ratings: Available
- EN 60335-1/DIN VDE 0700 T1: Compliant
- Voltage rating: 500 V/6 kV/3
- Wire gauge: No. 22-12 AWG
- Current rating: 250 V 20 A
- AC voltage: AC 400 V; 10 A
- Wire size: 1 – 1.5 mm2/1 – 2.5 mm2
- Poles: 4, 6, 8, 12, 16, 20
- Standard Pack: 29.400.0453.0, 29.401.0453.0, 2940006530, 2940106530, 29.400.0853.0, 29.401.0853.0, 29.400.1253.0, 29.401.1253.0, 294001630, 294011630, 2940020530, 2940120530
Buy the 07.250.1627.0 WIELAND ELECTRIC Terminal Strip Connector | myMectronic
Purchase the Wieland Electric 07.250.1627.0 terminal strip securely online and ensure reliable connections for your industrial equipment.
