WIELAND ELECTRIC 251370253 Modular Terminal Block
The Wieland Electric WK series modular terminal blocks represent a culmination of decades of experience in terminal block design. These blocks are engineered for rail mounting and offer a range of features designed to enhance both installation efficiency and operational reliability. Key features include rapid mounting tools, pressure connectors with high contact pressure, and vibration-resistant connections. The use of hardened steel and zinc-plated, chromated finishes ensures excellent corrosion resistance. The insulating housing, made from polyamid 6.6, provides flexibility and prevents breakage. These terminal blocks are ideal for various electrical and electronic applications, from industrial automation to power distribution.
WIELAND ELECTRIC 251370253 Modular Terminal Block Specifications:
- Metal parts: Steel, zinc plated and chromated
- Pressure connector: Steel, zinc plated and chromated
- Pressurescrew: Steel, zinc plated and chromated
- Currentbar: Copper or brass
- Springclip: Steel, zinc plated and chromated
- Insulating body: Polyamid6.6
- Dielectric strength: 40kv/mm
- Volumeresistivity: 1012 0cm
- Surface resistivity: 1010 0
- Dielectricconstant: 5at 1 kHz
- Continuous operating temperature range: -60° C to +100° C
- Short term withstand temperature: 170° C
