ABB 1SNA645034R2300 Interface Relay 1c/o 5VDC
The ABB RB121P-5VDC is a boxed interface relay designed for reliable control applications. It features a 5VDC input voltage, a 1SPDT contact capable of handling currents up to 6A, and a built-in LED for visual indication of relay status. The screw terminals provide secure and easy connections. This relay is commonly used in industrial automation, building management systems, and other applications requiring precise and dependable switching functionality. It adheres to various international standards and certifications, ensuring quality and safety.
ABB 1SNA645034R2300 Interface Relay 1c/o 5VDC Specifications:
- Extended Product Type: RB121P-5VDC
- Product ID: 1SNA645034R2300
- EAN: 4013614507977
- Catalog Description: RB121P-5VDC Interface relay R600 1c/o,A1-A2=5VDC,250V/10mA-6A
- Long Description: Screw relayRB121 5vdc : 5vdc input / 1SPDT 10 mA upto 6A with led
- Minimum Order Quantity: 10 piece
- Customs Tariff Number: 85364900
- Product Net Height: 67.5 mm
- Product Net Depth: 70 mm
- Product Net Weight: 0.02 kg
- Product Net Width: 6 mm
- Package Level 1 Width: 73 mm
- Package Level 1 Height: 71 mm
- Package Level 1 Length: 80 mm
- Package Level 1 Gross Weight: 0.23 kg
- Package Level 1 EAN: 3472596450342
- Package Level 1 Units: 10piece
- Sub-Function: Relay with built in LED
- Output: 1 c/o (SPDT) contact
- Output Signal: 12 ... 250 V AC / 10 mA ... 6 A
- Rated Control Supply Voltage: 5 V DC
- Terminal Type: Screw Terminals
- Function: Boxed interface relayR600
- RoHS Status: FollowingEU Directive 2011/65/EC
- Instructions and Manuals: 1SVC645000M9000
- CB Certificate: CB_DK-53188-UL
- CSA Certificate: CSA_254821
- cUR Certificate: cUR_E352056
- Data Sheet, Technical Information: 1SVC117001D0200
- Declaration of Conformity - CE: 1SVD982016-0000
- EAC Certificate: EAC_RU_C-FR.ME77.B.01634
- LR Certificate: LR_16_20068
- RoHS Information: 1SVD982016-4400
- UR Certificate: UR_E352056
- ETIM 4: EC001437 - Switching relay
- ETIM 5: EC001437 - Switching relay
- ETIM 6: EC001437 - Switching relay
- eClass: 7.0 27371601
- UNSPSC: 39121500
- Object Classification Code: K
