ABB F202PVB25003 Photovoltaic Earth Fault Protector
The F202PVB25003 is a type B residual current device designed specifically for photovoltaic solar energy systems. It offers protection against sinusoidal alternating, pulsating, and smooth DC earth fault currents, ensuring safety from indirect contacts and incorporating additional protections for direct contacts with a sensitivity of 30 mA. Suitable for solar installations with minimal separation between AC and DC systems, this device complies with IEC/EN 61008 and IEC 62423 standards. Its robust design ensures reliable operation, withstands harsh environmental conditions, and guarantees long electrical life for photovoltaic protection applications.
ABB F202PVB25003 Photovoltaic Earth Fault Protector Specifications:
- Rated residual operating current: 30 mA
- Rated voltage: 280 V AC
- Rated frequency: 50/60 Hz
- Tripping times: 14 ms for 300 ms, 40 ms for 5 x In
- Rated residual making and breaking capacity: 800 A
- Rated conditional residual short-circuit current: 10 kA
- Impact resistance: 20 g/20 ms duration
- Dimensions: 85 x 69 x 72 mm
- Mounting: DIN rail EN 60715
- Tightening torque: 3 Nm
- Electrical life: > 2000 switching cycles
- Protection standards: IEC 61008, IEC 62423
- Environmental resistance: cyclic damp/heat according to IEC 68-2-30
Buy the ABB Series F200 Residual Current Device: F202PVB25003
Purchase the ABB Series F200 residual current device F202PVB25003 online today and enhance the safety of your solar energy system. Designed specifically for photovoltaic applications, this type B RCD provides rapid trip times and high fault capacity, ensuring exceptional protection against earth faults. Its robust construction withstands harsh environments, offers long-lasting performance, and is easy to install on DIN rails. Secure your solar installation with a certified device that complies with IEC standards. Reliable, efficient, and essential for safe energy management—order now to safeguard your solar investments.
Order your ABB Series F200 residual current device F202PVB25003 today and ensure reliable earth fault protection for photovoltaic systems with certified quality.
Frequently Asked Questions
Where can I buy ABB F202PVB25003?
You can click on the BUY or RFQ button to purchase F202PVB25003 from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part F202PVB25003?
You can download the F202PVB25003 datasheet or visit the ABB website for support.
Who is the manufacturer of F202PVB25003?
ABB
