ABB 1SVR405654R0100 Pluggable LED Module
The ABB CR-P/M 92 plug-in module is a versatile accessory for the CR-P and CR-M range sockets. This module provides diode and a red LED indication, offering visual feedback for relay status. It operates on a rated control supply voltage of 110-230 V AC or 110 V DC, providing flexibility in various applications. The module features reverse polarity protection, enhancing system reliability. It's ideal for use in PCB and miniature relay sockets, making it suitable for a wide range of industrial control and automation systems. Its compact dimensions and ease of integration make it a valuable addition to any control panel.
ABB 1SVR405654R0100 Pluggable LED Module Specifications:
- Extended Product Type: CR-P/M 92
- Product ID: 1SVR405654R0100
- EAN: 4013614528798
- Minimum Order Quantity: 10 piece
- Customs Tariff Number: 85389099
- Product Net Width: 13 mm
- Product Net Height: 24 mm
- Product Net Depth / Length: 9 mm
- Product Net Weight: 0.003 kg
- Function: Accessory for interface relays CR-M
- Sub-Function: Pluggable function module for pcb and miniature relay sockets
- Sub-Function 2: Reverse polarity protection
- Output: none
- Output Signal: none
- Rated Control Supply Voltage (Us): 110 V DC
- RoHS Status: Following EU Directive 2011/65/EU
- Package Level 1 Width: 130 mm
- Package Level 1 Height: 180 mm
- Package Level 1 Depth / Length: 9 mm
- Package Level 1 Gross Weight: 0.032 kg
- Object Classification Code: K
- E-nummer: 4005386
- ETIM 4: EC002586 - Accessories for switching relay
- ETIM 5: EC002586 - Accessories for switching relay
- ETIM 6: EC002586 - Accessories for switching relay
- ETIM 7: EC002586 - Accessories for switching relay
- eClass: 7.0 27379208
- UNSPSC: 43172000
