ABB AF16301011 Industrial Power Contactor
ABB AF16-30-10-11 is a versatile three-pole IEC-rated contactor suitable for controlling power circuits up to 690 V AC and 220 V DC. It features an 18-amp rated operational current and can handle control voltages from 24 to 60 V AC/DC, making it ideal for motor control and non-inductive loads. The contactor includes built-in surge protection, minimal maintenance requirements, and multiple auxiliary contact options, with a compact design measuring 77mm deep, 86mm high, and 45mm wide, providing reliable performance in industrial environments.
ABB AF16301011 Industrial Power Contactor Specifications:
- Rated Operational Voltage: 690 V AC, 220 V DC
- Rated Operational Current AC-1 (Ie): 35A at 40°C
- Rated Operational Power AC-3 (Pe): 9 kW at 690 V
- Control Circuit Voltage Range: 24 to 60 V AC/DC
- Number of Main Contacts NC: 0
- Number of Auxiliary Contacts NO: 1
- Dimensions: Depth 77mm, Height 86mm, Width 45mm
- Material: Standard industrial-grade components
- Screw Terminals for wiring
- Protection Degree: IP20
- Standards Compliant: IEC 60947-4-1, IEC 60947-5-1
- Maximum Mechanical Switching Frequency: 1200 cycles/hour
- Maximum Electrical Switching Frequency: 1200 cycles/hour
- Operate Time: 38-95 ms
- Ambient Temperature Range: -25°C to +70°C
- Maximum Operating Altitude: 3000 meters
Buy the Buy ABB AF16-30-10-11 Part Number AF16301011 Online
Purchase the ABB AF16-30-10-11 contactor online for efficient power management in industrial applications. Featuring an 18-amp rating, this 3-pole device controls up to 690 V AC and 220 V DC loads. Its compact design measures 77mm deep, 86mm high, and 45mm wide, saving space in control panels. Built-in surge protection eliminates the need for additional suppressors, ensuring system reliability. Ideal for motor control and non-inductive loads, this contactor provides fast switching, durability, and precise control, making it a valuable component for automation and power switching needs.
Get ABB AF16-30-10-11 contactor today—built for industrial motor control with reliable performance and surge protection.
Frequently Asked Questions
Where can I buy ABB AF16301011?
You can click on the BUY or RFQ button to purchase AF16301011 from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part AF16301011?
You can download the AF16301011 datasheet or visit the ABB website for support.
Who is the manufacturer of AF16301011?
ABB
