ABB S202D20 Miniature Circuit Breaker
The product is a miniature circuit breaker designed for residential, commercial, and industrial applications. It features a two-pole configuration with a D trip characteristic, rated at 20A and operates at 400 V AC with a breaking capacity of up to 6 kA. The breaker has a compact design, mounting on a DIN rail, and includes screw terminals capable of accommodating flexible or stranded conductors with a torque of 2.8 Nm. It complies with IEC, UL, and CSA standards, ensuring safety and reliability in electrical distribution systems.
ABB S202D20 Miniature Circuit Breaker Specifications:
- Number of Poles: 2
- Tripping Characteristic: D
- Rated Current (In): 20A
- Rated Operational Voltage: 400 V AC
- Maximum Operating Voltage: 440 V AC
- Rated Short-Circuit Capacity (Icn): 6 kA at 230/400 V AC
- Rated Ultimate Short-Circuit Breaking Capacity (Icy): 20 kA
- Rated Service Short-Circuit Breaking Capacity (Ics): 15 kA
- Rated Impulse Withstand Voltage: 6 kV (sea level), 6.2 kV (2000 m)
- Rated Frequency: 50/60 Hz
- Housing Material: RAL 7035, insulating group II
- Degree of Protection: IP40
- Mounting: DIN rail TH35-15 or TH35-7.5
- Terminal Type: Screw terminals, accommodates flexible and stranded conductors 0.75–35 mm²
- Tightening Torque: 2.8 Nm
- Standards: IEC/EN 60898-1, IEC/EN 60947-2, UL 1077, CSA
- Environmental Conditions: Operation -25°C to +55°C; Storage 40°C to +70°C
- Shock & Vibration Resistance: IEC 60068-2-27, IEC 60068-2-6
- Dimensions: 69 mm depth, 88 mm height, 35 mm width
- Weight: 0.25 kg
Buy the Eaton Series S200 Miniature Circuit Breaker: 2 Poles, 20A, D Trip
Order the Eaton S200 series miniature circuit breaker with 20A capacity online today. Designed for reliability, safety, and easy DIN rail mounting, it features a D trip characteristic for efficient overload protection. Its compact size, screw terminals, and high breaking capacity make it ideal for residential, commercial, and industrial electrical systems. Enjoy fast delivery and seamless online purchasing ensures your electrical safety solutions are always available when needed. Upgrade your system now with this durable and compliant device for optimal performance.
Get Eaton S200 20A miniature circuit breaker today—built for precision, safety, and long-lasting durability in electrical distribution systems.
