ABB S204MD32 Miniature Circuit Breaker
The miniature circuit breaker is a reliable, current-limiting device designed for residential, commercial, and industrial use. It features two tripping mechanisms: delayed thermal for overload protection and electromechanical for short-circuit protection. With a rated current of 32A, it offers a breaking capacity of up to 10 kA at 230/400 V AC, complies with IEC standards, and includes a sealable operating handle with an IP40 degree of protection. Its compact design allows mounting on DIN rails, ensuring dependable circuit protection with high endurance and safety features.
ABB S204MD32 Miniature Circuit Breaker Specifications:
- Number of Poles: 4
- Tripping Characteristic: D
- Rated Current: 32A
- Rated Operational Voltage: 440 V AC
- Rated Insulation Voltage: 440 V AC
- Maximum Short-Circuit Capacity: 10 kA
- Rated Service Short-Circuit Breaking Capacity: 18.8 kA
- Rated Ultimate Short-Circuit Breaking Capacity: 25 kA
- Energy Limiting Class: 3
- Overvoltage Category: III
- Pollution Degree: 3
- Rated Impulse Withstand Voltage: 6.2 kV @ sea level
- Dielectric Test Voltage: 2 kV for 1 min
- Housing Material: RAL 7035 insulation group II
- Degree of Protection: IP40
- Electrical Endurance: 10,000 cycles
- Mechanical Endurance: 20,000 cycles
- Terminal Type: Screw terminals
- Tightening Torque: 2 Nm
- Mounting on DIN Rail: IEC 60715 compliant
- Standards: IEC/EN 60898-1, IEC/EN 60947-2
Buy the Eaton 2CDS274001R0821 – Reliable Circuit Breaker for Industrial Applications
Secure your electrical installations with the Eaton miniature circuit breaker designed for high durability and reliable circuit protection in industrial, commercial, and residential settings. Featuring thermal and electromagnetic trip mechanisms, rated at 32A with a high short-circuit capacity, it guarantees safety and compliance with IEC standards. Its compact DIN rail mounting makes installation straightforward and space-efficient. Trust in Eaton’s quality to safeguard your electrical systems from overloads and short circuits, ensuring operational safety and peace of mind for your projects.
Order your Eaton 2CDS274001R0821 miniature circuit breaker today and ensure your electrical systems operate with safety and dependability in demanding industrial environments.
Frequently Asked Questions
Where can I buy ABB S204MD32?
You can click on the BUY or RFQ button to purchase S204MD32 from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part S204MD32?
You can download the S204MD32 datasheet or visit the ABB website for support.
Who is the manufacturer of S204MD32?
ABB
