ABRACON ACAR0301SW2 Dual Band WiFi Chip Antenna
The ABRACON ACAR0301-SW2 is a compact, low-profile chip antenna engineered for dual-band WiFi applications. Its small size and omnidirectional radiation pattern make it suitable for integration into space-constrained devices such as wearables, IoT sensors, and drones. The antenna provides a gain of 1.0 dBi at 2.4 GHz and 2.5 dBi at 5.5 GHz, ensuring reliable wireless connectivity. It is designed for Pb-free assembly and is RoHS compliant, meeting modern environmental standards. Matching components are provided for optimal performance.
ABRACON ACAR0301SW2 Dual Band WiFi Chip Antenna Specifications:
- Working Frequency: 2400~2500MHz / 5150~5825MHz
- VSWR: 2:1
- Peak Gain (2400~2500MHz): Typ 1.0 dBi
- Peak Gain (5150~5825MHz): Typ 2.5 dBi
- Efficiency: 75% / 80%
- Polarization: Linear
- Impedance: 50 Ω
- Operating Temperature: -40˚C ~ 85˚C
- Storage Temperature: -40˚C ~ 85˚C
- Dimensions: 3.05 x 1.60 x 0.55 mm
- Refow Temperature (TL): 217°C
- Refow Time above TL (t L): 30-100 seconds
- Peak Temperature (TP): 260°C
- Peak Time (tp): 5-10 seconds
- Ramp-up Rate: 3°C /second
- Ramp-down Rate: 6°C / second
Buy the ACAR0301-SW2 ABRACON Dual Band WiFi Chip Antenna | myMectronic
Purchase the ABRACON ACAR0301-SW2 chip antenna securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy ABRACON ACAR0301SW2?
You can click on the BUY or RFQ button to purchase ACAR0301SW2 from an authorized ABRACON distributor.
How do I troubleshoot issues or seek technical support for part ACAR0301SW2?
You can download the ACAR0301SW2 datasheet or visit the ABRACON website for support.
Who is the manufacturer of ACAR0301SW2?
ABRACON
