ABRACON AX5PBF13125000C Crystal Oscillator
Enhance your communication and data transmission systems with this ultra-low jitter, power-optimized crystal oscillator. Designed in a compact 5.0 x 3.2 mm package, it offers exceptional frequency stability over temperature ranges from -40°C to +85°C with 420 ppm stability. Featuring versatile differential output options including LVPECL, LVDS, HCSL, and CML, it supports frequencies from 50MHz to 2100MHz. Its low power consumption, RoHS compliance, MSL 1 rating, and factory programmability make it ideal for networking, data centers, RF systems, and test measurement applications. Precise phase noise and jitter performance ensure reliable high-speed data integrity in demanding environments.
ABRACON AX5PBF13125000C Crystal Oscillator Specifications:
- Package Size: 5.0 x 3.2 mm, height 1.4 mm
- Frequency Range: 50 MHz to 2100 MHz
- Frequency Accuracy: ±10 ppm (initial) @ 25°C with total stability ±40 ppm over -40°C to +85°C
- Stability: 420 ppm over -40°C to +85°C
- Supply Voltage: 2.25V to 3.3V (options available)
- Output Types: LVPECL, LVDS, HCSL, CML
- Phase Jitter: 125 fs typ RMS (12kHz-20MHz BW)
- Peak RMS phase jitter: 118-165 fs depending on frequency
- Power Consumption: approx. 60 mA (LVDS at 3.3V)
- RoHS/RoHS II Compliant, MSL=1
- Temperature Range: -40°C to +85°C
- ESD Sensitive, suitable for industrial environments
- Factory programmable options available
- Reflow temperature: peak 260°C with specific ramp-up/down profiles
- Pin configuration supports differential output and output enable/disable controls
Buy the Abracon 1809001-2015 – Reliable Crystal Oscillator for Industrial Applications
Secure your Abracon AX5PBF13125000C crystal oscillator online now and ensure your communication and data systems operate with ultra-low jitter and outstanding stability. With broad frequency options from 50 MHz to 2100 MHz, this compact 5.0 x 3.2 mm device offers excellent phase noise performance, low power consumption, and industrial temperature stability. Perfect for networking, RF, datacenter, and test measurement applications, order today to experience reliable high-frequency performance for demanding environments.
Order your Abracon Series AX5PBF13125000C crystal oscillator today and give your high-speed systems the dependable timing they need for industrial and data center applications.
Frequently Asked Questions
Where can I buy ABRACON AX5PBF13125000C?
You can click on the BUY or RFQ button to purchase AX5PBF13125000C from an authorized ABRACON distributor.
How do I troubleshoot issues or seek technical support for part AX5PBF13125000C?
You can download the AX5PBF13125000C datasheet or visit the ABRACON website for support.
Who is the manufacturer of AX5PBF13125000C?
ABRACON
