AEMC Instruments SR632 AC Current Probe
The AEMC SR632 is a versatile AC current probe designed for industrial and utility environments, capable of measuring up to 1200A AC with high accuracy. Its ergonomic, rounded jaw allows easy clamping around conductors up to two 500 MCM cables. Suitable for use with DMMs, power meters, oscilloscopes, and recorders, it features a 1000:5 ratio, low phase shift, and a broad frequency response of 30Hz to 5kHz. Conforming to safety standards, it offers reliable measurements for power quality, waveform analysis, and load monitoring in demanding industrial applications.
AEMC Instruments SR632 AC Current Probe Specifications:
- Measurement Range: 0.1 to 1200A
- Transformation Ratio: 1000:5
- Output Signal: 5 mA per A measured (5A @ 100A)
- Accuracy (1000A Range): <6% + 0.1A for 1-20A, 5% for 20A, 3% for 50A, 1.5% for 200A, 1% for 1000A and 1200A
- Phase Shift (1000A Range): 5° at 20A, 3° at 50A, 1.5° at 200A, 1° at 1000A and 1200A
- Frequency Range: 30Hz to 5kHz
- Maximum Conductor Size: 2.05 inches (52mm)
- Jaw Opening: 2.25 inches (67mm)
- Operating Temperature: -14° to 122°F (-10° to 50°C)
- Maximum Bus Bar Size: 1.95 x 0.19 inches (50 x 5mm)
- Weight: 1.21 lbs (550g)
- Material: Polycarbonate handles and jaws, UL94 VO, Double Insulated
- Safety Certifications: UL, CE Mark, EN 61010-2-032, 600V Cat. III
- Operating Humidity: 0 to 85% @ 35°C
Buy the AEMC SR632 U–Reliable AC Current Probe for Industrial Applications
Purchase the AEMC SR632 AC current probe online today—engineered for high accuracy, safety, and durability. Featuring a 1000:5 ratio, broad frequency response, large jaw opening, and ergonomic design, this probe ensures reliable measurements for power quality, waveform analysis, and industrial load monitoring. Its UL and CE certifications guarantee safety compliance, making it an essential tool for electricians, power engineers, and technicians working with high currents. Order now to maximize efficiency and measurement precision in demanding industrial settings.
Get AEMC SR632 today—built for precision, robustness, and high-current measurement in industrial environments.
Frequently Asked Questions
Where can I buy AEMC Instruments SR632?
You can click on the BUY or RFQ button to purchase SR632 from an authorized AEMC Instruments distributor.
How do I troubleshoot issues or seek technical support for part SR632?
You can download the SR632 datasheet or visit the AEMC Instruments website for support.
Who is the manufacturer of SR632?
AEMC Instruments
