AEMC INSTRUMENTS SR759 AC Current Probe
The AEMC SR759 current probe offers precise measurements with four selectable ranges: 1A, 10A, 100A, and 1000A. Its large jaw can accommodate conductors up to two 500 kcmil in size, making it suitable for industrial power quality analysis, large load monitoring, and leakage current detection. The probe provides an output voltage proportional to the measured current, facilitating compatibility with DMMs, oscilloscopes, recorders, and power meters. Designed with high sensitivity, minimal phase shift, and safety standards including EN 61010, it ensures reliable, accurate performance for electrical testing and waveform analysis.
AEMC INSTRUMENTS SR759 AC Current Probe Specifications:
- Measurement Range: 1mA to 1200A
- Output Signal: 1000mV at 1A, 100mV at 10A, 10mV at 100A, 1mV at 1000A
- Jaw Opening: 2.25 inches (67mm)
- Maximum Conductor Size: 2.05 inches (52mm)
- Bus Bar Size: 1.95 x 0.19 inches (50 x 5mm)
- Dimensions: 4.37 x 8.50 x 1.77 inches (111 x 216 x 45mm)
- Weight: 1.21 lbs (550g)
- Operating Temperature: -14°F to 122°F (-10°C to 50°C)
- Storage Temperature: -4°F to 158°F (-20°C to 70°C)
- Frequency Range: 30Hz to 3000Hz
- Load Impedance: 100kΩ minimum
- Working Voltage: 600Vrms Cat. III
- Material: Polycarbonate, UL94 VO, Handles: Polycarbonate + ABS
- Safety Certification: UL approved US/Canada, CE Mark
- Double Insulation: Yes
Buy the Buy AEMC AC Current Probe Model SR759 Online
Purchase the AEMC SR759 AC Current Probe online today to leverage its versatile measurement capabilities, high accuracy, and safety compliance. Featuring four selectable ranges from 1A to 1000A, large jaw capacity, and an ergonomic design, it simplifies power quality assessments, waveform analysis, and monitoring large industrial loads. Its compatible output signals and safety certifications ensure reliable performance with DMMs, recorders, oscilloscopes, and power meters. Get dependable, professional-grade current measurement tools for advanced electrical diagnostics and power management today.
Order your AEMC Series SR759 AC Current Probe today and ensure precise current measurements for power quality and industrial testing.
