ALPHA WIRE 19353BK003 Industrial Power Cable
This is a 3-conductor portable power cable with a chlorinated polyethylene jacket, designed for heavy-duty industrial applications. Made with 16 AWG copper conductors and neoprene insulation, it withstands harsh environments with excellent flexibility and durability. Rated for 600V and temperatures from -40°C to 90°C, it offers Sunlight Resistance, a 10 times cable diameter bend radius, and pull tension of up to 61 lbs. Compliant with UL, CSA, and CE standards, it's ideal for rugged electrical wiring in industrial settings.
ALPHA WIRE 19353BK003 Industrial Power Cable Specifications:
- Conductor: 16 AWG Copper
- Insulation: Neoprene, 0.031 inch wall
- Jacket: Chlorinated Polyethylene, 0.065 inch wall, Black
- Temperature Range: -40°C to 90°C
- Voltage Rating: 600V
- Bend Radius: 10 times cable diameter
- Pull Tension: 61 lbs maximum
- Sunlight Resistance: Yes
- Capacitance: 39 pF/ft @1 kHz
- Inductance: 0.2 μH/ft
- Conductor DCR: 4.1 Ω/1000 ft @20°C
- Packaging: 250 ft spool, dimensions 12 x 10 x 5 inches
- Certifications: UL, CSA, CE, RoHS, REACH compliant
Buy the Buy Alpha Wire Part Number 1935/3 Online
Purchase the Alpha Wire 1935/3 power cable online today to ensure reliable performance in demanding environments. This robust 3-conductor cable features neoprene insulation and a chlorinated polyethylene jacket for resistance to heat, sunlight, and chemical exposure. Rated at 600V with a temperature range of -40°C to 90°C, it is UL, CSA, and CE compliant. Ideal for heavy-duty industrial wiring, its 250 ft spool makes installation efficient. Trust Alpha Wire for high-quality, durable electrical solutions.
Buy Alpha Wire 1935/3 power cable now and experience unmatched durability and safety for industrial electrical wiring.
Frequently Asked Questions
Where can I buy ALPHA WIRE 19353BK003?
You can click on the BUY or RFQ button to purchase 19353BK003 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 19353BK003?
You can download the 19353BK003 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 19353BK003?
ALPHA WIRE
