ALPHA WIRE 65264CYSL005 Control Cable
This premium control cable features a 4-conductor design with 26 AWG bare copper conductors and PVC insulation, suitable for industrial automation and electrical applications. It includes a copper braid shield with 85% coverage for enhanced EMI protection, oil-resistant PVC jackets in slate color, and a flexible construction rated for 90°C and 600V, making it ideal for control and instrumentation use. The cable's flexible design ensures easy installation with a minimum bend radius of 8 times the cable diameter, supporting reliable performance in demanding environments.
ALPHA WIRE 65264CYSL005 Control Cable Specifications:
- Conductor: 26 AWG Bare Copper
- Insulation Wall Thickness: 0.022" PVC
- Jacket Wall Thickness: 0.030" PVC
- Jacket Color: Slate
- Shield: Copper braid, 85% coverage
- Cable Diameter: 0.219+/- 0.016 inches
- Temperature Range: -40°C to 90°C static, -5°C to 90°C dynamic
- Voltage Rating: 600 V AC
- Capacitance: 24.2 pF/ft @1 kHz
- Ground Capacitance: 44 pF/ft @1 kHz
- Inductance: 0.26 μH/ft
- Conductor DCR: 38 mΩ/1000 ft @20°C
- Shield DCR: 3.2 mΩ/1000 ft @20°C
- Bend Radius: 8X cable diameter
- Pull Tension: 15.3 lbs
- Length Options: 100 ft, 500 ft, 1000 ft spools
- Compliance: UL, CSA, CE (RoHS 2, RoHS 3, REACH)
Buy the Alpha Wire 65264CY – Reliable Control Cable for Industrial Applications
Purchase the Alpha Wire Control Cable 65264CY online today for your industrial control and automation needs. Featuring four conductors with 26 AWG copper, durable PVC insulation, and an 85% copper braid shield, this cable ensures excellent EMI protection and flexibility. Rated for 90°C and 600V, it is perfect for demanding electrical environments. Available in various spool lengths, it offers reliable performance with a minimum bend radius of 8 times the diameter. Order now for trusted quality and fast delivery to ensure your project’s success.
Get Alpha Wire 65264CY today—built for precision, EMI shielding, and long-lasting durability in demanding control systems.
Frequently Asked Questions
Where can I buy ALPHA WIRE 65264CYSL005?
You can click on the BUY or RFQ button to purchase 65264CYSL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 65264CYSL005?
You can download the 65264CYSL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 65264CYSL005?
ALPHA WIRE
