ALPHA WIRE F22134WH026 Heat Shrink Tubing
The FIT-221-3/4 WH026 is a white heat shrink tubing made from cross-linked polyolefin, designed for electrical insulation and protection. It features a 2:1 shrink ratio and a minimum tensile strength of 1500 psi, providing reliable sealing and mechanical reinforcement for cable terminations and component insulation. Manufactured with high-quality compounds under strict quality controls, this tubing exhibits excellent physical properties such as low longitudinal shrinkage and broad temperature tolerance. It has a minimum dielectric strength of 500V/mil, begins shrinking at 90°C, fully recovers at 121°C, and operates effectively within a temperature range of -55°C to 135°C. Suitable for safety and industrial applications, it offers both functional and aesthetic benefits when used on OEM equipment or in various installations.
ALPHA WIRE F22134WH026 Heat Shrink Tubing Specifications:
- Material: Cross linked polyolefin
- Color: White
- Shrink Ratio: 2:1
- Minimum Recovered ID: 0.375 inches
- Minimum Supplied Diameter: 0.750 inches
- Wall Thickness (In): 0.030
- Temperature Range: -55°C to 135°C
- Shrink Initiation Temperature: 90°C
- Full Recovery Temperature: 121°C
- Tensile Strength: 1500 psi, min
- Dielectric Strength: 500 V/mil, min
- Volume Resistivity: 1×10⁴ ohm-cm, min
- Water Absorption: 0.50%, max
- Chemical Resistance: No corrosion after 16 hours at 0°C
- Environmental Compliance: RoHS, REACH, California Proposition 65
- Shelf Life: 5 years at 18°C to 35°C
- Certifications: UL 224, CSA C22.2
Buy the Buy Alpha Wire Heat Shrink Tubing Part Number F22134WH026 Online
Purchase Alpha Wire heat shrink tubing F22134WH026 online today for dependable electrical insulation and protective covering. Made from high-quality cross-linked polyolefin, it offers a 2:1 shrink ratio, enabling easy installation on wires and components. This durable tubing withstands broad temperature ranges from -55°C to 135°C, ensuring long-lasting performance in industrial, safety, and OEM applications. With certified compliance to UL and CSA standards, along with RoHS and REACH adherence, this tubing is ideal for professionals seeking reliable, safe, and environmentally friendly insulation solutions for various electrical and mechanical needs.
Get Alpha Wire F22134WH026 today—designed for reliable electrical insulation with a 2:1 shrink ratio and excellent mechanical properties.
Frequently Asked Questions
Where can I buy ALPHA WIRE F22134WH026?
You can click on the BUY or RFQ button to purchase F22134WH026 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part F22134WH026?
You can download the F22134WH026 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of F22134WH026?
ALPHA WIRE
