ALPHA WIRE PMC25SL080 Cable Gland
The PMC25 SL080 fits Standard Dome Design Metric Cable Gland offers reliable cable strain relief and environmental protection. Made from high-strength polyamide 6 in a slate color (RAL 7001), it is resistant to dust, dirt, sand, and water, with an IP68 rating that withstands 5 bar pressure for 30 minutes. The gland is supplied with a locknut and gasket for complete sealing and strain relief. It features robust rubber seals to prevent water ingress, making it suitable for applications in renewable energy, industrial automation, and electrical equipment. It is UL listed and CSA certified, with an operating temperature range from -20°C to +100°C (permanent) and -30°C to +150°C (intermittent). Its flammability rating is UL94V-2.
ALPHA WIRE PMC25SL080 Cable Gland Specifications:
- Material: Polyamide 6 (PA 6)
- Protection Class: IP 68, 5 Bar, 30 min
- Flammability: UL94V-2
- Temperature Rating: -20°C to +100°C (permanent), -30°C to +150°C (intermittent)
- Color: Gray, RAL 7001
- Thread Type: Metric according to EN 60423
- Size: M-25x1.5
- Clamping Range: 11.0-17.0 mm
- Thread Length: 29 mm
- Outer Diameter: 32 mm
- Spanner Width: 29 mm
- Max Height: 35 mm
- Includes: Locknut and gasket
- Suitable for industrial automation, renewable energy, electrical equipment
- Standards: UL Listed, CSA Certified
- Corrosion resistant materials ensure durability in harsh environments
Buy the Alpha Series PMC: Cable Gland M-25x1.5: PMC25SL080
Secure and protect electrical cables with the high-quality cable gland. Made from durable polyamide 6, it offers IP68 water and dust resistance, UL and CSA certifications, and a temperature range suitable for demanding environments. Perfect for industrial automation, renewable energy, and electrical installations, this gland includes a locknut and gasket for complete sealing. Its robust rubber seals prevent water ingress, ensuring long-term performance. Easy to install, it delivers reliable strain relief and environmental protection for a broad range of electrical projects.
Buy Alpha Series PMC25SL080 now and experience unmatched reliability and performance in industrial automation and environmental sealing.
Frequently Asked Questions
Where can I buy ALPHA WIRE PMC25SL080?
You can click on the BUY or RFQ button to purchase PMC25SL080 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part PMC25SL080?
You can download the PMC25SL080 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of PMC25SL080?
ALPHA WIRE
