ALPHA WIRE PVC10520CLEAR1000 PVC Insulated Wire
ALPHA WIRE's PVC10520-CLEAR-1000 is a PVC insulated wire designed for general-purpose applications requiring flexibility and durability. Constructed with a non-shrinkable PVC tubing, this wire offers good electrical insulation and resistance to abrasion. It is UL rated for 300V (sizes #24 through #1) and 600V (sizes 5/16 through 2”), making it suitable for a wide range of electrical systems. The wire is RoHS compliant and meets various industry standards including ASTM D922, MIL-I-631D, and AMS-DTL-23053. Its halogen-free and lead-free composition further enhances its environmental profile.
ALPHA WIRE PVC10520CLEAR1000 PVC Insulated Wire Specifications:
- Tubing Type: Non Shrinkable
- Tubing Material: PVC
- Minimum ID(In): 0.032
- Maximum ID(In): 0.039
- Minimum Wall Thickness(In): 0.016
- Color(s): BLACK, CLEAR
- UL Standard: 224, VW-1
- CSA Standard: 198
- Military Standard: MIL-I-631D, Type F, Form U, Subform Ua, Grade C
- ASTM D 922: Compliant
- Temperature Range: -20 to 105°C
- Tensile Strength: 2780psi, Min
- Elongation: 260%, Min
- Specific Gravity: 1.35, Max
- Dielectric Strength: 870 V/mil, Min
- Volume Resistivity: 2x1014ohm-cm, Min
- Corrosion Resistance: no corrosion
- Fungus Resistance: Pass
- Halogen Free: No
- Lead Free: Yes
- UL Voltage Rating (Sizes #24-#1): 300V
- UL Voltage Rating (Sizes 5/16"-2"): 600V
Buy the PVC10520-CLEAR-1000 ALPHA WIRE PVC Insulated Wire | myMectronic
Purchase PVC10520-CLEAR-1000 ALPHA WIRE PVC Insulated Wire securely online and ensure your project's success.
Buy Now
Frequently Asked Questions
Where can I buy ALPHA WIRE PVC10520CLEAR1000?
You can click on the BUY or RFQ button to purchase PVC10520CLEAR1000 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part PVC10520CLEAR1000?
You can download the PVC10520CLEAR1000 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of PVC10520CLEAR1000?
ALPHA WIRE
