AMPHENOL ADVANCED SENSORS T302215K1MX CO2 Sensor
The Telaire T3022 Series is an IP65-rated non-dispersive infrared (NDIR) CO2 sensor designed for OEM installations in environmental monitoring and HVAC control. It offers accurate measurements over a range of 0 to 5000 ppm, with a compact size of approximately 60mm x 35mm x 15mm. The sensor features self-calibration with ABC Logic™, extended temperature and storage ranges, and digital output via I2C protocols. Suitable for harsh environments, it provides reliable, drift-free operation with factory calibration and long-term stability.
AMPHENOL ADVANCED SENSORS T302215K1MX CO2 Sensor Specifications:
- Measurement Range: 0 to 5000 ppm
- Dimensions: 60mm x 35mm x 15mm
- Accuracy: 400-5000 ppm + 75 ppm or 10% of reading
- Temperature Dependence: 0.2% FS per °C
- Stability: < 2% FS over 15 years
- Response Time: 7 minutes
- Signal Update: Every 4 seconds
- Warm Up Time: <2 minutes (operational), 10 minutes (max accuracy)
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -40°C to 70°C
- Ingress Protection: IP65
- Power Supply: 4.5-5.5 VDC, Peak 200mA
- Output: Digital, I2C protocol
- Materials & Certifications: UL94 5VA, REACH, ROSH, Prop65
- Calibration: Factory pre-calibrated, ABC Logic self-calibration technology
- Connector: JST EHR-4, Molex 171856-0004
Buy the Amphenol Series T3022 CO2 Sensor: T3022-1-5K-5-1
Purchase the Amphenol T3022 Series CO2 Sensor online today to ensure accurate, dependable carbon dioxide measurements for HVAC, demand ventilation, and environmental control systems. This durable, IP65-rated sensor features factory calibration and self-calibration technology, offering long-term stability and minimal maintenance in various harsh environments. Its compact size and digital I2C output make integration simple for OEM applications. Secure your supply now and enhance your building management systems with this high-performance, reliable CO2 measurement solution.
Buy Amphenol T3022-1-5K-5-1 CO2 sensor now and experience reliable, long-term performance in demanding environmental conditions.
