AMPHENOL ANYTEK OQ0271500000G Terminal Block Socket
The part is a straight pluggable terminal block socket designed for through-hole mounting. It features a 5mm pitch spacing, has 2 poles, and comes in a green plastic housing made of thermoplastic resin. The copper alloy terminals are tin-plated, providing good electrical conductivity and corrosion resistance. The socket meets UL94 V-0 flammability standards and operates within a temperature range of -40°C to 115°C. It is cULus certified, rated for 300VAC voltage and 12A current, making it suitable for industrial applications.
AMPHENOL ANYTEK OQ0271500000G Terminal Block Socket Specifications:
- Housing Material: Thermoplastic resin, UL 94V-0 rated
- Terminal Material: Copper alloy, tin-plated
- Voltage Rating: 300VAC
- Current Rating: 12A
- Temperature Range: -40°C to 115°C
- Pitch: 5mm
- Number of Poles: 2
- Mounting Type: Through-hole
- Color: Green (RAL 6018)
- Flammability Standard: UL94 V-0
- Operating Voltage: 300 VAC
- Rated Current: 12 A
- Dimensions: Housing length varies with pole count, typical housing width approximately 8.50 mm, terminal length around 7.2 mm
- Certification: UL Listed, cULus certified
Buy the Buy FCI Terminal Block Socket Part Number OQ0271500000G Online
Purchase the high-quality FCI terminal block socket online today and ensure your projects benefit from durable, UL94 V-0 flame-retardant material and precise 5mm pitch spacing. This 2-pole, through-hole mounted connector offers excellent electrical performance with 300VAC voltage and 12A current ratings, suitable for industrial and electronic applications. Easy to install and compliant with safety standards, it guarantees dependable connectivity and long-lasting operation. Order now to enhance your manufacturing or repair processes with trusted components.
Order your FCI Series06-500 terminal block socket today and enhance your electronic assemblies with reliable, UL94 V-0 rated quality.
Frequently Asked Questions
Where can I buy AMPHENOL ANYTEK OQ0271500000G?
You can click on the BUY or RFQ button to purchase OQ0271500000G from an authorized AMPHENOL ANYTEK distributor.
How do I troubleshoot issues or seek technical support for part OQ0271500000G?
You can download the OQ0271500000G datasheet or visit the AMPHENOL ANYTEK website for support.
Who is the manufacturer of OQ0271500000G?
AMPHENOL ANYTEK
