AMPHENOL INDUSTRIAL ALM07FD2116P Circular Connector
Amphenol's Amphe-Lite M3 series is a high-performance circular connector designed for harsh environments, featuring scoop-proof shells, quick-mating bayonet coupling, and superior silicone seals for fluid resistance. Suitable for control systems, aerospace, telecommunication, medical instrumentation, and vehicle signal interconnects, these connectors meet MIL-DTL-38999 Series III standards. They offer excellent EMI shielding, corrosion resistance with Gray ZnNi plating, and a wide range of sizes and keyway options, ensuring reliable, quick, and durable connections in demanding applications.
AMPHENOL INDUSTRIAL ALM07FD2116P Circular Connector Specifications:
- Operating Temperature: -65°C to +125°C
- Mating Cycles: Minimum 500
- Insulation Resistance: > 100 MΩ at room temperature
- Salt Spray Resistance: Gray ZnNi plating for 500 hours
- EMI Shielding Range: 100MHz to 10GHz with minimum 50dB attenuation
- Connection Types: Pin and socket crimp contacts, removable
- Shell Sizes: 9, 11, 13, 15, 17, 19, 21, 23, 25
- Keyway Options: 5 different configurations (A, B, C, D, N)
- Coupling: Acme threaded or bayonet locking
- Ingress Protection: IP67 rated in mated condition
- Materials: Rigid dielectric insert, stainless steel contact shroud
- Plating: Gray Zinc Nickel (RoHS compliant)
- Vibration Resistance: Sine and random vibration tests passed
- Shock Resistance: Up to 300g for 3ms half-sine shock
Buy the Amphenol Series M3 Circular Connector: ALM07FD2116P
Shop the Amphenol ALM07FD2116P circular connector online today to benefit from rapid, reliable connections with scoop-proof shells and superior EMI shielding. Designed for demanding applications, this connector features quick-mating bayonet coupling, corrosion-resistant Gray ZnNi plating, and multiple keyway options. Its IP67 rating ensures excellent protection against dust and water. Ideal for aerospace, control systems, and industrial use, this connector delivers durability, easy installation, and dependable performance in harsh conditions.
Get Amphenol ALM07FD2116P today—built for precision, quick-mating, and long-lasting durability in harsh environments.
Frequently Asked Questions
Where can I buy AMPHENOL INDUSTRIAL ALM07FD2116P?
You can click on the BUY or RFQ button to purchase ALM07FD2116P from an authorized AMPHENOL INDUSTRIAL distributor.
How do I troubleshoot issues or seek technical support for part ALM07FD2116P?
You can download the ALM07FD2116P datasheet or visit the AMPHENOL INDUSTRIAL website for support.
Who is the manufacturer of ALM07FD2116P?
AMPHENOL INDUSTRIAL
