AMPHENOL INDUSTRIAL C10647176001 high current compression lug
The Amphenol SurLok high-performance compression lug with plastic housing utilizes RADSOK technology for high amperage and reliable connections in power distribution. Designed for easy field installation with standard crimp tools, it features an integral locking mechanism and a protective plastic cover, ensuring voltage and current integrity. Suitable for various high current applications, it offers high reliability, RoHS compliance, and competitive electrical performance, making it ideal for medical equipment, process control, heavy machinery, and rail industries. The lug supports multiple wire sizes up to 300 Amps.
AMPHENOL INDUSTRIAL C10647176001 high current compression lug Specifications:
- UL listed under file UL1977
- Engagement force: ~2 lbs. — 5 Ibs. for insertion, ~10 Ibs. — 15 Ibs. for locking
- Separation force: ~10 Ibs. — 15 Ibs.
- Contact surfaces are silver plated; wire crimp barrel is matte tin
- Compatible with wire sizes from 8 AWG to 2/0 AWG, supporting currents from 70 to 300 Amps
- Housing available in standard black; other colors available on request
- Pin diameter ranges from 3.6mm to 10.3mm
- Thread options include M3x0.5 to M10x1.5
Buy the Amphenol Series SurLok High Current Compression Lug: C10647176001
Purchase the Amphenol SurLok high-current compression lug online today and benefit from a reliable high amperage connection solution. Designed with RADSOK technology, it ensures excellent electrical performance and easy field installation using standard crimp tools. The lug features a protective plastic housing and an integral locking mechanism for secure, durable connections in demanding industrial, medical, and rail applications. Order now for efficient power distribution that combines safety, reliability, and ease of use.
Buy Amphenol C10647176001 high-current compression lug with plastic housing now and experience unmatched reliability, easy installation, and superior power performance.
Frequently Asked Questions
Where can I buy AMPHENOL INDUSTRIAL C10647176001?
You can click on the BUY or RFQ button to purchase C10647176001 from an authorized AMPHENOL INDUSTRIAL distributor.
How do I troubleshoot issues or seek technical support for part C10647176001?
You can download the C10647176001 datasheet or visit the AMPHENOL INDUSTRIAL website for support.
Who is the manufacturer of C10647176001?
AMPHENOL INDUSTRIAL
