AMPHENOL INDUSTRIAL C1073866610M3 Micro-B Circular Connector
Amphenol's Micro-B Series Connectors are compact, lightweight circular connectors designed for industrial applications requiring high-density insert patterns, reliable EMI shielding, and rugged construction. Made with an aluminum shell and incorporating a triple bayonet coupling (quarter-turn), they ensure quick mating and high durability. Features include stamped & formed contacts, an internal EMI grounding spring for optimal shell-to-shell conductivity, and multiple mounting options, such as inline and flange mount. They withstand harsh environments, offering up to IP67 protection, and support high mating cycles, making them ideal for automotive, automation, instrumentation, robotics, and communication systems in demanding operational settings.
AMPHENOL INDUSTRIAL C1073866610M3 Micro-B Circular Connector Specifications:
- Shell Material: Aluminum
- EMI-Ring: Copper Alloy
- Retaining Ring: Stainless steel
- Wave Ring: Stainless steel
- Insert Material: Plastic (PA66)
- Contact Material: Copper Alloy
- Contact Plating: Tin/Gold Plated
- Temperature Range: -40°C to 125°C
- Ingress Protection: IP54 with heat shrink, IP67 with cable gland backshell
- Test Current: 3A at #22D contact
- Operating Voltage: AC 250V RMS
- Test Voltage: AC 500V RMS
- Insulation Resistance: 1000 MΩ at 500V
- Contact Resistance: Max 22mΩ
- Mating Cycles: 500 cycles
- Vibration Resistance: In accordance with EIA-364-28D
- Salt Spray: 500 hours salt spray with Gray ZnNi plating
Buy the Amphenol Series Micro-B Circular Connector: C1073866610M3
Purchase the Amphenol Micro-B Circular Connector series online today for a compact, durable, and high-performance connection solution. Designed for demanding industrial applications, these connectors are lightweight with high-density contacts, ensuring excellent EMI shielding and IP67 protection when paired with cable glands or heat shrink. They feature a quick quarter-turn bayonet coupling, multiple mounting options including flange mount, and support up to 500 mating cycles. Ideal for automotive, automation, robotics, telecommunications, and instrumentation environments where robust, reliable, and cost-effective connectors are crucial.
Buy Amphenol Micro-B Series Connectors now and experience unmatched reliability and performance in harsh industrial environments.
Frequently Asked Questions
Where can I buy AMPHENOL INDUSTRIAL C1073866610M3?
You can click on the BUY or RFQ button to purchase C1073866610M3 from an authorized AMPHENOL INDUSTRIAL distributor.
How do I troubleshoot issues or seek technical support for part C1073866610M3?
You can download the C1073866610M3 datasheet or visit the AMPHENOL INDUSTRIAL website for support.
Who is the manufacturer of C1073866610M3?
AMPHENOL INDUSTRIAL
