AMPHENOL INDUSTRIAL LPT02SE1626P027LC industrial connector
The Amphenol Industrial LPT Series is a lightweight, durable connector based on MIL-C-26482 Series I and the original PT series, featuring an aluminum shell design. It includes a standard PT shell with a coupling nut, making it intermateable with the PT series. The connector has three retention tines with stamped and formed crimp contacts for secure insertion and retention. It supports wire gauges from 22 AWG (0.34 mm²) to 12 AWG (3.5 mm²) and offers quick, positive coupling with a 5-key/keyway system to prevent mismating. Available in five shell styles: box mounting, jam nut, straight plug, wall mounting, and cable connecting receptacle. Suitable for applications in automation, process control, commercial vehicles, energy, industrial automation, instrumentation, and power management.
AMPHENOL INDUSTRIAL LPT02SE1626P027LC industrial connector Specifications:
- Shell Material: Aluminum
- Insert Material: Plastic
- Contact Plating: Tin/Nickel/Gold plated
- Temperature Range: -40°C to +125°C
- Ingress Protection: IP67 & IP69K in mated condition
- Maximum Operating Voltage: 500V
- Test Voltage: 2300V AC
- Number of Poles: 8, 10, 12, 14, 16, 18, 20, 22, 24
- Contact No.: 12-24 depending on size
- Crimp or Machined contacts available
- Connector Styles: Box mounting, jam nut, straight plug, wall mounting, cable connecting receptacle
- Shell Sizes: #8 to #24
- Operating Temperature: -40°C to 125°C
- Ingress Protection Ratings: IP67 & IP69K when mated
- Shock & Vibration Resistance: High
- Certificates: UL/IEC/TUV certifications in process
- Mating Cycles: 500
Buy the Buy Amphenol LPT Series Connector Part Number LPT02SE1626P027LC Online
Enhance your industrial and automation systems with the Amphenol LPT Series connector, offering lightweight aluminum shell, multiple mounting options, and secure crimp contacts. Designed to withstand harsh environments with IP67/IP69K ratings and operating temperatures from -40°C to 125°C, this connector ensures reliable power and signal transmission. Its quick bayonet coupling, multiple shell styles, and certifications like UL/TUV make it ideal for a wide range of industrial, energy, and transportation applications. Purchase online now for dependable, high-quality interconnect solutions.
Get Amphenol LPT Series Connector today—built for durability, easy installation, and high-performance in industrial automation and harsh environments.
Frequently Asked Questions
Where can I buy AMPHENOL INDUSTRIAL LPT02SE1626P027LC?
You can click on the BUY or RFQ button to purchase LPT02SE1626P027LC from an authorized AMPHENOL INDUSTRIAL distributor.
How do I troubleshoot issues or seek technical support for part LPT02SE1626P027LC?
You can download the LPT02SE1626P027LC datasheet or visit the AMPHENOL INDUSTRIAL website for support.
Who is the manufacturer of LPT02SE1626P027LC?
AMPHENOL INDUSTRIAL
