Advantech Automation ADAM3016AE Strain Gauge Signal Conditioner
The ADAM-3017 is an externally powered IEPE signal conditioner designed for accurate measurement of strain gauge inputs with isolation protection. It features integrated electronic piezoelectric (IEPE) excitation, a bandwidth of 2.4 kHz, and isolation mode rejection >100 dB at 50/60 Hz. The device provides bipolar voltage output up to 45 V, current output options of 0-20 mA, and operates within a temperature range of -10°C to 70°C. Its robust design ensures reliable performance in industrial environments, with low power consumption and safe isolation capabilities.
Advantech Automation ADAM3016AE Strain Gauge Signal Conditioner Specifications:
- Integrated electronic piezoelectric (IEPE) excitation
- Bandwidth: 2.4 kHz (typical)
- Isolation mode rejection: >100 dB at 50/60 Hz
- Current output: 0-20 mA with 5% accuracy
- Voltage output: Bipolar up to 45 V, unipolar 0-10 V
- Impedance: <50 Ohms
- Operating temperature: -10°C to 70°C
- Storage temperature: -25°C to 85°C
- Power supply: 24 V AC ±10%
- Dimensions: 232 x 101 x 93.5 mm
- Enclosure: ABS
- Isolation voltage: 4,000 V AC (three-way)
Buy the Buy ADAM-3017 Isolated Strain Gauge Input Module Part Number ADAM3017-AE Online
Purchase the ADAM-3017 externally powered IEPE signal conditioner online now for accurate strain gauge measurements. This module offers high isolation, a bandwidth of 2.4 kHz, and stable performance in industrial environments. Its bipolar voltage output up to 45 V and current outputs up to 20 mA make it suitable for dynamic and static measurements. Compact and robust, this device ensures reliable operation with low power consumption and advanced isolation protection, perfect for precision monitoring in manufacturing and research applications.
Get ADAM-3017 externally powered IEPE signal conditioner today—designed for precision strain measurement and reliable industrial performance.
Frequently Asked Questions
Where can I buy Advantech Automation ADAM3016AE?
You can click on the BUY or RFQ button to purchase ADAM3016AE from an authorized Advantech Automation distributor.
How do I troubleshoot issues or seek technical support for part ADAM3016AE?
You can download the ADAM3016AE datasheet or visit the Advantech Automation website for support.
Who is the manufacturer of ADAM3016AE?
Advantech Automation
