ALPHA WIRE 1857BL005 Control Wire
The 1857 BL005 is a 100-foot blue hookup wire featuring a tinned copper conductor and PVC insulation. Designed for control cabinet applications in protected environments, it is suitable for use with machine tools, high-temperature ovens, or off-road construction equipment. This wire offers excellent durability against wear and abrasion, along with resistance to oil, solvents, and chemicals. It operates within a temperature range of -55°C to 105°C, has a maximum pull tension of 13.9 lbs, and a nominal inductance of 0.04 µH per foot. Commonly used in defense, military, aerospace, and industrial sectors, it meets stringent electrical and mechanical standards.
ALPHA WIRE 1857BL005 Control Wire Specifications:
- Conductor: Tinned copper
- Insulation: PVC, 0.010" wall
- Color: Blue
- Length: 100 feet
- Temperature Range: -55°C to 105°C
- Voltage Rating: 600 V
- Maximum Pull Tension: 13.9 lbs
- Inductance: 0.04 µH/ft
- Conductor Resistance: 6.3 Ω/1000 ft at 20°C
- Bend Radius: 10X cable diameter
- Applicable Standards: MIL-W-16878E/1
- RoHS & REACH Compliant
Buy the AlphaWire 1857BL005 – Reliable Control Wire for Industrial Applications
Get the AlphaWire 1857BL005 100-foot blue hookup wire online now for your industrial and control cabinet needs. Featuring tinned copper conductors and PVC insulation, this cable is perfect for demanding environments. It offers high durability against wear, abrasion, oil, and chemicals, with a temperature rating from -55°C to 105°C. Ideal for aerospace, military, and industrial sectors, it complies with critical standards like MIL-W-16878E/1. RoHS and REACH compliance make it a safe and reliable choice for your wiring solutions.
Order your AlphaWire 1857BL005 100-foot blue hookup wire today and ensure dependable performance in your control and industrial projects.
Frequently Asked Questions
Where can I buy ALPHA WIRE 1857BL005?
You can click on the BUY or RFQ button to purchase 1857BL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 1857BL005?
You can download the 1857BL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 1857BL005?
ALPHA WIRE
