ALPHA WIRE 2634BL005 High-Temperature Hookup Wire
The product is a high-temperature resistant hookup wire with a 34 AWG solid copper conductor, nickel-plated for enhanced connectivity, and a 0.006-inch wall thickness PFA insulation in multiple colors, including orange. Suitable for environments requiring sunlight and chemical resistance, water resistance, and compliance with EU and RoHS regulations. Designed to operate over a broad temperature range from -150°C to 300°C, with a voltage rating of 600 V, low inductance, and specific physical dimensions, making it ideal for industrial and electronic applications demanding durability and safety.
ALPHA WIRE 2634BL005 High-Temperature Hookup Wire Specifications:
- Conductor: 34 AWG solid copper, nickel-plated
- Insulation: PFA, 0.006-inch wall thickness
- Color: Multiple including orange
- Temperature Range: -150°C to 300°C
- Voltage Rating: 600 V
- Inductance: 0.08 LH/ft
- Conductor DCR: 297 Q/1000ft @20°C
- Bend Radius: 10X Cable Diameter
- Pull Tension: 0.31 Lbs Max
- Core Diameter: 2.75 inches
- Length: 1000 ft or 100 ft spools
- Compliance: RoHS 2 & 3, REACH, EU Low Voltage Directive, China ROHS
Buy the Alpha Wire Series High-Temp Hookup Wire: 2634BL005
Order Alpha Wire 2634BL005 high-temperature hookup wire online today and take advantage of fast shipping, competitive pricing, and trusted quality. Perfect for demanding environments requiring excellent chemical, water, and sunlight resistance, this wire operates from -150°C to 300°C with a 600 V rating. It features a 34 AWG solid copper conductor, nickel plating for corrosion resistance, and PFA insulation in versatile colors including orange. Ideal for industrial, electronic, and control applications, it provides superior performance, durability, and compliance with international safety standards. Make your purchase today and ensure reliable electrical connectivity with a dependable, top-grade wire.
Buy Alpha Wire 2634BL005 high-quality hookup wire now and ensure durable, reliable electrical connections for industrial and electronic applications.
Frequently Asked Questions
Where can I buy ALPHA WIRE 2634BL005?
You can click on the BUY or RFQ button to purchase 2634BL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 2634BL005?
You can download the 2634BL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 2634BL005?
ALPHA WIRE
