ALPHA WIRE 2636WH005 Hookup Wire
The product is a flexible, weather-resistant hookup wire suitable for various electrical applications. It features a 36 AWG solid copper conductor with a 0.005 inch diameter, nickel plating for corrosion resistance, and a 0.006-inch wall insulation made of PFA, available in multiple colors including white, black, red, green, yellow, blue, brown, and orange. This wire supports a voltage rating of 600 V, with a temperature range from -150°C to 300°C. Its durability, flexibility, and environmental resistance make it ideal for industrial, electronic, and outdoor wiring projects.
ALPHA WIRE 2636WH005 Hookup Wire Specifications:
- Conductor: 36 AWG, solid copper, 0.005 inches diameter, nickel plated
- Insulation: PFA, 0.006 inches wall thickness, available in multiple colors including white, black, red, green, yellow, blue, brown, and orange
- Voltage Rating: 600 V
- Temperature Range: -150°C to 300°C
- Bend Radius: 10X cable diameter
- Pull Tension: 0.2 Lbs maximum
- Inductance: 0.09 LH/ft, nominal
- Resistance: 471 Ω per 1000 ft at 20°C
- Spool Dimensions: 2.75 x 2 x 1.125 inches, continuous length options 100 ft or 1000 ft
Buy the Alpha Wire Series 711 Hookup Wire: 2636WH005
Order Alpha Wire 2636WH005 online today to ensure high-quality, weather-resistant electrical wiring for your industrial or outdoor applications. This flexible hookup wire features a 36 AWG copper conductor with nickel plating, offering excellent corrosion resistance, and a PFA insulation wall for high-temperature environments. Rated at 600 V, it can withstand temperatures from -150°C to 300°C, making it suitable for demanding conditions. Purchase now to benefit from fast shipping, trusted quality, and seamless online ordering for your electrical needs.
Buy Alpha Wire 2636WH005 now and experience unmatched reliability and performance with durable, weather-resistant hookup wiring for industrial and outdoor projects.
