ALPHA WIRE 86702CYSL002 2 Conductor Data Cable
The ALPHA WIRE 86702CY SL002 is a flexible data cable designed for demanding applications requiring continuous flexing and reliable signal transmission. It consists of two 22 AWG tinned copper conductors, each insulated with semi-rigid PVC. These conductors are cabled together and wrapped with nonwoven polyester tape, followed by an aluminum/mylar shield with a tinned copper drain wire. The cable is jacketed with PVC and marked with key product information. This cable is suitable for applications such as robotics, factory automation, and medical equipment where flexibility and signal integrity are critical.
ALPHA WIRE 86702CYSL002 2 Conductor Data Cable Specifications:
- Conductor AWG: 22 (19/34)
- Conductor Material: Tinned Copper
- Insulation Material: PVC
- Insulation Wall Thickness: 0.010"
- Pair Construction: 2/Cond Cabled Together
- Twists per Foot (Pair): 9.6 (min)
- Twists per Foot (Cable): 6.0 (min)
- Shield Material: Flex Alum/Mylar Tape
- Shield Coverage: 25% (min)
- Drain Wire AWG: 26 (7/34)
- Drain Wire Material: Tinned Copper
- Braid Coverage: 85% (min)
- Jacket Material: PVC
- Jacket Wall Thickness: 0.040"
- Jacket Color: SLATE
- Print: ALPHA WIRE-* P/N 86702CY 2PR 22 AWG XTRAGUARD(R) CONTINUOUS FLEX DATA CABLE (UL) 105C TYPE CM --- C(UL) CMG OR AWM 2661 105C 300V --- LLXXXXXX CSA AWM I/II A/B FT4 105C 300V CE ROHS (SEQ FOOTAGE) * = Factory Code
- Temperature Range (Static): -10 to 105°C
- Temperature Range (Dynamic): +5 to 105°C
- Bend Radius (Static): 10X Cable Diameter
- Bend Radius (Dynamic): 15X Cable Diameter
- Pull Tension (Max): 31 Lbs
- Sunlight Resistance: Yes
- Voltage Rating: 300 VRMS
- Mutual Capacitance: 34 pF/ft @ 1 kHz
- Ground Capacitance: 61 pF/ft @ 1 kHz
- Characteristic Impedance: 53 Ω
- Inductance: 0.17 µH/ft
- Conductor DCR: 15.6 Ω/1000ft @ 20°C
- OA Shield DCR: 3.4 Ω/1000ft @ 20°C
- UL Style: 10002, 2661, CM
- CSA Rating: AWM I/II A/B, C(UL) TYPE CMG, FT4
- RoHS Compliant: Yes
- REACH Compliant: Yes
