ALPHA WIRE SW11WH008 Spiral Wrap Tubing
The SW11 WH008 Spiral Wrap Tubing offers a flexible, flame-retardant solution for wire harnessing, cabling, and bundling in industrial settings. Made from durable polyethylene, it features a 0.250-inch outside diameter, 0.160-inch inside diameter, and 0.045-inch wall thickness with a right-hand pitch of 0.375 inches. Suitable for applications requiring insulation and organization, its semi-rigid structure ensures a secure fit around wires, maintaining flexibility, and facilitating easy breakout points for connections. Compliant with EU RoHS2 and REACH regulations, it is ideal for modern electrical installations and cable routing.
ALPHA WIRE SW11WH008 Spiral Wrap Tubing Specifications:
- Material: Polyethylene
- Color: White
- Flamability: Flame Retardant
- Outside Diameter: 0.250" ± 0.020"
- Inside Diameter: 0.160" Nominal
- Wall Thickness: 0.045" Nominal
- Pitch: 0.375" Nominal
- Pitch Direction: Right Hand
- Temperature Rating: -20 to +80°C
- Packaging options: 25 FT, 100 FT, 500 FT
- Maximum package length: 3 pieces, with each length at least 10 ft
- Applicable Standards: EU RoHS2, REACH compliant
Buy the Alpha Wire SW11 – Reliable Spiral Wrap for Industrial Applications
Order the Alpha Wire SW11 Spiral Wrap Tubing online now to ensure optimal wire protection and cable management in industrial environments. This flame-retardant polyethylene tubing provides flexibility, easy installation, and reliable bundling for wires and cables. Suitable for various lengths up to 500 feet, it ensures organized wiring solutions. Its compatibility with environmental standards like RoHS2 and REACH makes it ideal for compliant electrical installations. Invest in high-quality spiral wrap tubing for safe, efficient, and professional cable routing and management today.
Get Alpha Wire SW11 today—built for flexible wire management and durable cable organization.
