ALPHA WIRE SW12WH005 Spiral Wrap Tubing
The SW12 spiral wrap tubing is made of polyethylene, designed for bundling, protecting, and organizing wires and cables efficiently. It features a 0.375-inch outside diameter and a 0.271-inch inside diameter, with a wall thickness of 0.052 inches and a pitch of 0.438 inches in a right-hand direction. Flame retardant and rated for temperatures from -20°C to +80°C, this tubing offers flexible installation without tools, facilitating ease of use in industrial wiring harnessing and cable management. Suitable for applications requiring reliable wire protection and bundling.
ALPHA WIRE SW12WH005 Spiral Wrap Tubing Specifications:
- Material: Polyethylene
- Color: White
- Flamability: Flame Retardant
- Outside Diameter: 0.375 inch +/- 0.020 inch
- Inside Diameter: 0.271 inch nominal
- Wall Thickness: 0.052 inch nominal
- Pitch: 0.438 inch nominal
- Pitch Direction: Right Hand
- Temperature Rating: -20°C to +80°C
- Packaging: 100FT or 25FT packages, up to 3 lengths, minimum 10 ft each
Buy the AlphaWire SW12 – Reliable Spiral Wrap Tubing for Industrial Applications
Enhance your cable management with durable and flexible spiral wrap tubing designed for industrial wiring and bundling. Made of flame-retardant polyethylene, it ensures reliable wire protection while maintaining flexibility and ease of installation. The SW12 tubing features a 0.375-inch outside diameter, right-hand pitch, and is suitable for applications demanding strict safety and performance standards. Available in 25 ft or 100 ft packages, this versatile tubing simplifies wiring harnessing, reduces installation time, and improves overall project organization for electrical systems.
Order your AlphaWire Series SW12 spiral wrap tubing today and give your wiring projects the dependable protection and organization they deserve.
Frequently Asked Questions
Where can I buy ALPHA WIRE SW12WH005?
You can click on the BUY or RFQ button to purchase SW12WH005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part SW12WH005?
You can download the SW12WH005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of SW12WH005?
ALPHA WIRE
